Images are for reference purposes only and product appearances/colours may vary.
Experience Primal performance with the Prime Radeon RX 9070 XT graphics card featuring a compact 2.5-slot design for expansive compatibility, enhanced by a phase-change GPU thermal pad and a triple-fan setup for supreme cooling. The Prime Radeon RX 9070 XT features a 2.5 slot design with a carefully arranged layout for the shroud, heatsink and heat pipes to let the three Axial-tech fans leverage chassis side-panel ventilation and deliver optimal thermal performance. Large backplate vents significantly enhance heat dissipation, helping to keep the GPU cooler during intense tasks. This additional airflow helps ensure optimal temperatures, boosting performance, longevity and stability by defending against overheating and thermal throttling. By melting to effectively fill the gaps between the GPU and the thermal module, a premium phase-change GPU thermal pad provides superior thermal conductivity and enhanced heat dissipation, ensuring optimal performance and longevity for graphics cards under heavy loads. ASUS GPU Guard applies adhesive to secure all four corners to reduce the risk of cracks, while a GPU bracket helps ensure uniform mounting pressure and extra stability. The PCB is reinforced by a backplate that adds structural rigidity, helping to prevent flex and to protect components and trace pathways from damage.
| Graphics Processing | Radeon RX 9070 XT |
| Core Clock | Boost Clock: Up to 3030 MHz (Reference card: 2970 MHz) Game Clock: Up to 2480 MHz (Reference card: 2400 MHz) |
| Stream Processors | 4096 |
| Ray Accelerators | 64 |
| Memory Clock | 20000 MHz |
| Memory Size | 16 GB |
| Memory Type | GDDR6 |
| Memory Bus | 256 bit |
| Memory Bandwidth (GB/sec) | 640 GB/s |
| Card Bus | PCI-E 5.0 x16 |
| Digital max resolution | 7680x4320 |
| Multi-view | 4 |
| Card size | 312 x 130 x 50 mm |
| PCB Form | ATX |
| DirectX | 12 Ultimate |
| OpenGL | 4.6 |
| Recommended PSU | 750W |
| Power Connectors | 3 x PCIe 8-Pin |
| Output | 3 x DisplayPort 2.1a 1 x HDMI 2.1 |
| Multi-GPU Support | No |
| Accessories | Thank You Card Speedsetup Manual |
| Manufacturer | |
| Manufacturer's Website | Link * |
| Product Website | Link * |
| Warranty Information | |
| Warranty Duration | 3 Years |
ASUS PRIME Radeon RX 9070 XT OC Edition 16GB GDDR6 Graphics Card, 16GB
- AMD Radeon RX 9070 XT Graphics Processor
- Base Clock: 1660 MHz
- Boost Clock: Up to 3030 MHz
- Stream Processors: 4,096 Stream Processors
- Ray Accelerators: 64 Ray Accelerators
- AI Accelerators: 128 AI Accelerators
- Compute Units: 64 Compute Units
- Memory: 16GB GDDR6
- Effective Memory Clock: 20,000 MHz
- Real Time Ray Tracing
- AMD FSR 4 AI Upscaling Technology
- Reinforced Structure with Metal Backplate
- Phase-Change GPU Thermal Pad
- 3 x DisplayPort 2.1a, 1 x HDMI 2.1
- 3 x 8-Pin PCIe Power Connectors
- 3 Year Warranty
- Product Code: 90YV0L71-M0NA00
- Availability:
In Stock
Lead Times:
- In Stock with Progenix: Ready for collection/dispatch once payment clears
- In Stock: 1-3 working days until dispatched or ready for collection
- Out Of Stock: Contact us to see if this item will be restocked.
-
R17,010
