Taichi represents the philosophical state of undifferentiated absolute and infinite potential. A motherboard that fulfills every task – with style! Become like water. Shapeless, formless, versatile for any situation. Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the CPU with enhanced performance and OC capability. The reinforced DIMM slot is surfaced mounted onto the motherboard to give better physical strength as well as a more stable memory signal, with this superior revolutionary design, it is able to dramatically overclock DRAM module up to insane frequency. Due to the unique electrical architecture of DDR5 DIMM, there’s a high risk of damaging the memory module if AC power isn’t disconnected properly during removal or installation. To prevent this, ASRock has implemented a trouble free protection circuit on every DDR5 motherboard, lowers the risk of damaging your memory module. Compares to conventional DIP style PCIe slot, the SMT type PCIe slot improves signal flow and maximize stability under high speed, a key breakthrough to fully support the lighting speed of the latest PCIe 5.0 standard. The Blazing OC Tuner allows AM5 CPU to switch between OC mode and PBO(Precision Boost Overdrive) mode when the CPU current hits threshold. Anything above current threshold will engage manual OC mode; if below current threshold then will engage Precision Boost Overdrive mode. This idea is to combine overclocking on all cores and automatic boost on a single core to get the best performance out of your CPU. There is no need to enter BIOS to setup up, you can modify all the settings on time under OS.

CPU
  • Supports AMD Socket AM5 Ryzen 7000 Series Processors
Chipset
  • AMD X670
Memory
  • Dual Channel DDR5 Memory Technology
  • 4 x DDR5 DIMM Slots
  • Supports DDR5 non-ECC, un-buffered memory up to 6600+(OC)
  • Max. capacity of system memory: 128GB
  • Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
Onboard Graphics

Integrated Graphics Processor:

  • 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
  • 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 60Hz

Only the CPU's embedded graphics can be displayed through USB4 ports. If you want to display to a Type-C monitor, please use CPU models with embedded graphics.

USB4 graphics output may not be compatible with certain Type-C monitors. Please use graphics card outputs instead.

Audio

5.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec)

  • WIMA Audio Capacitors (For Front Outputs)
  • ESS SABRE9218 DAC for Front Panel Audio (130dB SNR)
  • Individual PCB Layers for R/L Audio Channel
  • Impedance Sensing on Rear Out port
  • Nahimic Audio
LAN

2.5 Gigabit LAN 10/100/1000/2500 Mb/s

  • Killer E3100G
  • Supports Killer LAN Software
  • Supports Killer DoubleShot Pro
Wireless Communication Module

802.11ax Wi-Fi 6E Module

  • Supports IEEE 802.11a/b/g/n/ac/ax
  • Supports Dual-Band 2x2 with extended 6GHz band support
    * Wi-Fi 6E (6GHz band) will be supported by Microsoft Windows 11. The availability will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows® Update and software updates once available.
  • 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
  • Supports Bluetooth + High speed class II
  • Supports MU-MIMO
  • Supports Killer LAN Software
  • Supports Killer DoubleShot Pro
Expansion Slots

CPU:

  • 2 x PCIe 5.0 x16 Slots (PCIE1 and PCIE2), support x16 or x8/x8 modes
    * 15μ Gold Contact in VGA PCIe Slot (PCIE1)

Chipset:

  • 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
Multi-Graphics Technology
  • Support for AMD CrossFire
Storage Interface

CPU:

  • 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode

Chipset:

  • 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2230/2242/2260/2280/22110 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes
  • 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode
  • 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode
  • 4 x SATA3 6.0 Gb/s Connectors

ASMedia ASM1061:

  • 4 x SATA3 6.0 Gb/s Connectors
    * If M2_2 is occupied by a SATA-type M.2 device, SATA3_A1 will be disabled.
USB

Rear:

  • 2 x USB4 Type-C
  • 5 x USB 3.2 Gen2 Type-A
  • 3 x USB 3.2 Gen1

Front:

  • 1 x USB 3.2 Gen2x2 Type-C
  • 4 x USB 3.2 Gen1
  • 4 x USB 2.0

All USB ports support ESD Protection

Internal I/O Connectors
  • 1 x Power LED and Speaker Header
  • 1 x RGB LED Header
    * Supports in total up to 12V/3A, 36W LED Strip
  • 3 x Addressable LED Headers
    * Support in total up to 5V/3A, 15W LED Strip
  • 1 x CPU Fan Connector (4-pin)
    * CPU_FAN1 supports the fan power up to 1A (12W).
  • 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
    * CPU_FAN2/WP_3A supports the fan power up to 3A (36W).
  • 6 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)
    * CHA_FAN1~6/WP support the fan power up to 2A (24W).
    * CPU_FAN2/WP_3A and CHA_FAN1~6/WP can auto detect if 3-pin or 4-pin fan is in use.
  • 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
  • 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
  • 1 x Front Panel Audio Connector (15μ Gold Audio Connector)
  • 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
  • 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
  • 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)
  • 1 x Dr. Debug with LED
  • 1 x Power Button with LED
  • 1 x Reset Button with LED
Back Panel Connectors
  • 2 x Antenna Ports
  • 1 x HDMI Port
  • 1 x Optical SPDIF Out Port
  • 2 x USB4 Type-C Ports (40 Gb/s)
  • * Supports USB PD 3.0 up to 9V@3A (27W) / 5V@3A (15W) charging
  • 5 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (ReDriver) (USB32_12 are Lightning Gaming Ports. USB32_3 supports Ultra USB Power.)
  • 3 x USB 3.2 Gen1 Ports
  • 1 x RJ-45 LAN Port
  • 1 x Clear CMOS Button
  • 1 x BIOS Flashback Button
  • 1 x Line Out Jack (Gold Audio Jack)
  • 1 x Microphone Input Jack (Gold Audio Jack)
I/O Controller
  • iTE I/O Controller Chip
H/W Monitoring
  • Voltage detection
  • Temperature detection
  • Fan speed detection
  • Water cooling flow rate detection
  • Fan fail warning
  • Fan speed control
    * Whether the fan speed control function is supported will depend on the fan you install.
BIOS
  • 256Mb AMI UEFI Legal BIOS with GUI support
  • ASRock Full HD UEFI
  • ASRock Auto Driver Installer
  • ASRock Instant Flash
Unique Features

Superb Productivity

  • PCIe Gen5 (Graphics, M.2)
  • Blazing M.2 Gen5 Fan Heatsink
  • Dual Channel DDR5
  • USB4 Type-C Ports (40 Gb/s)

Rock-Solid Durability

  • Ultra Low-Loss PCB
  • 24+2+1 Power Phase, 105A SPS with Enlarged Heatsink Armor
  • Flexible Integrated I/O Shield
  • Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)

Ultrafast Gaming

  • Killer 2.5G LAN, Killer 802.11ax Wi-Fi 6E Module
  • Killer DoubleShot Pro
  • ASRock Lightning Gaming Ports

EZ Update

  • BIOS Flashback Button
  • ASRock Auto Driver Installer
Bundled Software
  • ASRock Motherboard Utility (A-Tuning)
  • Killer Control Center
  • ASRock Polychrome SYNC
Operating System
  • Support for Windows 10 64-bit / Windows 11 64-bit
Form Factor
  • E-ATX Form Factor, 30.5cm x 26.7cm

Manufacturer
Manufacturer's WebsiteLink *
Product WebsiteLink *
Warranty Information
Warranty Duration3 Years
* These links will redirect to an external website which may be governed by its own privacy policy. We do not share customer information with external sites outside of what's lined out in our Privacy Policy.

Write a review

Note: HTML is not translated!
    Bad           Good

ASRock X670E Taichi with Wi-Fi, AMD X670 Chipset, Socket AM5, E-ATX Desktop Motherboard
