The ZenWiFi XD6 system consists of up to a pair of ASUS AX5400 WiFi 6 routers, featuring unique technologies that give you superfast, reliable and secure WiFi connections — inside or outside your home! ASUS ZenWiFi XD6 gives you alternative backhaul options: Ethernet and WiFi. The router intelligently chooses the most reliable method for you based on connection quality. If you prefer, you can also manually choose the type of backhaul connection. ZenWiFi XD6 puts your WiFi into top gear! With a total bandwidth of up to 5400 Mbps, it's up to 2.2X faster than WiFi 5 routers. AiProtection Pro with Advanced Parental Controls is free for life. It gives you total peace of mind, and you can keep an eye on everything that's happening on your network via the mobile app. Instant Guard gives you one-click secure internet access via ZenWiFi XD6 from anywhere in the world, thanks to its encrypted data-tunneling VPN technology. With ZenWiFi XD6 , you can take your home network with you wherever you go — and say goodbye to web-based third-party VPNs! ZenWiFi XD6 works perfectly with smart-home services- including Alexa skills. Even non-experts can quickly set up AiMesh technology, while more experienced users will appreciate the comprehensive advanced networking features.
| Model | ZenWiFi XD6S (W-1-PK) |
| Wireless Standard | IEEE 802.11a, 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax |
| Maximum Speed | 802.11a: Up to 54 Mbps 802.11b: Up to 11 Mbps 802.11g: Up to 54 Mbps 802.11n: Up to 500 Mbps 802.11ac: Up to 4333 Mbps 802.11ax (2.4GHz): Up to 574 Mbps 802.11ax (5GHz): Up to 4804 Mbps |
| Connectivity | 1 x 100/1000 RJ45 WAN/LAN Port 1 x 100/1000 RJ45 LAN Port |
| WPS | Yes |
| Security | WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS Support |
| Antennas | 6 x internal |
| Warranty | 3 Years |
Detailed Information
| Model Name | XD6S (W-1-PK) |
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) IPv4 IPv6 |
| Product Segment | AX5400 Ultimate AX Performance: 5742 Mbps + 4804 Mbps |
| AX Technology | Yes |
| Data Rate | 802.11a: Up to 54 Mbps 802.11b: Up to 11 Mbps 802.11g: Up to 54 Mbps WiFi 4 (802.11n) (1024QAM): Up to 500 Mbps WiFi 5 (802.11ac) (1024QAM): Up to 4333 Mbps WiFi 6 (802.11ax (2.4GHz): Up to 574 Mbps WiFi 6 (802.11ax) (5GHz): Up to 4804 Mbps |
| Antenna | Internal Antenna x 6 |
| Transmit/Receive | 2.4GHz 2x2 5GHz 4x4 |
| Processor | 1.5 GHz Tri-Core Processor |
| Memory | 128 MB Flash 512 MB RAM |
| Boosts Speed | OFDMA (Orthogonal Frequency Division Multiple Access) 1024-QAM High Data Rate 20/40/80/160 MHz Bandwidth |
| Operating Frequency | 2.4 GHz / 5 GHz |
| Ports | RJ45 for Gigabit BaseT for WAN/LAN x 1 RJ45 for Gigabit BaseT for LAN x 1 |
| Buttons | WPS Button Reset Button |
| LED Indicators | Power LED |
| Power Supply | AC Input: 110v-240v, 50-60Hz DC Output: 12v with max 2A current |
| Package Contents | ZenWiFi XD6S RJ45 Ethernet Cable Power Adapter Wall Mount Kit Quick Start Guide Warranty Card |
| Product Weight (Each) | 425g |
| AiMesh | AiMesh Primary AiMesh Router AiMesh Node |
| Router App | ASUS Router App |
| Alexa | Supports Alexa Skill |
| AiProtection | AiProtection Pro Router Security Assessment Malicious Site Blocking Two-Way IPS Infected Device Prevention and Blocking |
| Parental Controls | Parental Control Parental Control Customized Internet Schedule |
| Traffic Controls | Adaptive QoS Bandwidth Monitor Bandwidth Limiter Maximum Bandwidth Limiter Rule: 32 Traditional QoS Traditional QoS Rule: 32 Real-Time Traffic Monitor Wired Traffic Monitor Wireless Traffic Monitor Traffic Analyzer Website History |
| Wireless | IPv6 UTF-8 SSID Guest Network Maximum Guest Network Rule: 9 Guest Network Connection Time Limit Guest Network Encryption : WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise WPS WiFi MAC Address Filter Maximum MAC Filters: 64 Wireless Scheduler Airtime Fairness Universal Beamforming Explicit Beamforming |
| WAN | Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP Dual WAN Port Forwarding Maximum Port Forwarding Rule: 64 Port Triggering DMZ DDNS Let's Encrypt |
| LAN | DHCP Server IGMP Snoooping IPTV Manually Assign IP Addresses Maximum Manually Assign IP Rule Address: 64 |
| VPN | VPN Client L2TP VPN Client OVPN VPN Client PPTP VPN Server IPSec VPN Server OVPN VPN Server PPTP |
| Administration | Operating mode : Wireless router mode Range extender mode Access point mode Media bridge mode Operating system : ASUSWRT Free OS upgrade Firewall Maximum Firewall keyword filter : 64 Maximum Firewall network service filter : 32 Maximum Firewall URL filter : 64 Wake on LAN (WOL) SSH Configuration backup and restore Diagnosis tools Feedback system System log |
| Manufacturer | |
| Manufacturer's Website | Link * |
| Product Website | Link * |
| Warranty Information | |
| Warranty Duration | 3 Years |
ASUS ZenWiFi XD6S AX5400 Wi-Fi 6 (802.11ax) Dual Band Mesh-Enabled Wireless Router, White — Single Pack
- Product Code: 90IG06F0-MO3B60
- Availability:
Out Of Stock
Lead Times:
- In Stock with Progenix: Ready for collection/dispatch once payment clears. The cut-off for same-day dispatch is 12:00pm on business days.
- In Stock with Supplier: 1-3 business days until dispatched or ready for collection
- Out Of Stock: Contact us to see if this item will be restocked.
