• AMD Socket AM5 for AMD Ryzen 7000 Series Desktop Processors


• AMD X670


• 4 x DIMM, Max. 128GB, DDR5

• 6400+(OC) / 6200(OC) / 6000(OC) / 5800(OC) / 5600 / 5400 / 5200 / 5000 / 4800 ECC and Non-ECC, Un-buffered Memory
• Dual Channel Memory Architecture
• Supports AMD EXTended Profiles for Overclocking (EXPO)
• OptiMem II
  * Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.

Integrated Graphics Processor:

• 1 x DisplayPort
  * Supports max. 8K@60Hz as specified in DisplayPort 1.4.
• 1 x HDMI port
  * Supports 4K@60Hz as specified in HDMI 2.1.

Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC

• Impedance sense for front and rear headphone outputs

• Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
• Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
• High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
• Supports up to 32-Bit/192 kHz playback
  * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
• Audio Features
  Power pre-regulator reduces power input noise to ensure consistent performance
  Premium audio capacitors
  Dedicated audio PCB layers
  Audio cover
  Unique de-pop circuit

• 1 x Realtek 2.5Gb Ethernet
• ASUS LANGaurd

Wi-Fi 6E

• 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
• Supports 2.4/5/6GHz frequency band
• Bluetooth v5.2
  * WiFi 6E 6GHz regulatory may vary between countries.

AMD Ryzen 7000 Series Desktop Processors:

• 1 x PCIe 5.0 x16 slot(s)


AMD X670 Chipset:

• 1 x PCIe 4.0 x16 slot (supports x4 mode)

• 1 x PCIe 4.0 x4 slots

• Support for AMD CrossFire technology


Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports

AMD Ryzen 7000 Series Desktop Processors:

• M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)

• M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

AMD X670 Chipset:

• M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)
  * M.2_2 slot shares bandwidth with SATA_1&2. When M.2_w runs at PCIe x4 mode, SATA_1&2 will be disabled.
• M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
• 4 x SATA 6Gb/s ports

AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10.

Rear USB (Total 10 ports)

• 1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C)

• 4 x USB 3.2 Gen 2 port(s) (3 x Type-A + 1 x USB Type-C)
• 5 x USB 3.2 Gen 1 port(s) (4 x Type-A + 1 x USB Type-C)

Front USB (Total 9 ports)

• 1 x USB 3.2 Gen 2 connector (supports USB Type-C)

• 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
• 3 x USB 2.0 headers support additional 6 USB 2.0 ports

Fan and Cooling related

• 1 x 4-pin CPU Fan header

• 1 x 4-pin CPU OPT Fan header
• 1 x 4-pin AIO Pump header
• 4 x 4-pin Chassis Fan headers
• 1 x W_PUMP+ header

Power related

• 1 x 24-pin Main Power connector
• 2 x 8-pin +12V Power connector

Storage related

• 4 x M.2 slots (Key M)
• 4 x SATA 6Gb/s ports

USB

• 1 x USB 3.2 Gen 2 connector (supports USB Type-C)

• 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
• 3 x USB 2.0 headers support additional 6 USB 2.0 ports

Miscellaneous

• 2 x Addressable Gen 2 headers

• 1 x AURA RGB header
• 1 x Clear CMOS button
• 1 x COM Port header
• 1 x CPU Over Voltage jumper
• 1 x Front Panel Audio header (AAFP)
• 1 x Power button
• 1 x SPI TPM header (14-1pin)
• 1 x 20-3 pin System Panel header with Chassis intrude function
• 1 x Thermal Sensor header
• 1 x Thunderbolt  header

• 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)

• 4 x USB 3.2 Gen 2 port(s) (3 x Type-A, 1 x USB Type-C)
• 5 x USB 3.2 Gen 1 port(s) (4 x Type-A, 1 x USB Type-C)
• 1 x DisplayPort
• 1 x HDMI port
• 1 x Wi-Fi Module
• 1 x Realtek 2.5Gb Ethernet port
• 5 x Audio jacks
• 1 x BIOS FlashBack  button

• Not Specified

• Voltage detection

• Temperature detection
• Fan speed detection
• Water cooling flow rate detection
• Fan fail warning
• Fan speed control
  * Whether the fan (pump) speed control function is supported will depend on the fan(pump) you install.

• 256 Mb Flash ROM, UEFI AMI BIOS


ASUS 5X PROTECTION III

• DIGI+ VRM (- Digital power design with DrMOS)
• ESD Guards
• LANGuard
• Overvoltage Protection
• Safeslot Core+
• Stainless-Steel Back I/O

ASUS Q-Design

• M.2 Q-Latch
• PCIe Slot Q-Release
• Q-Connectir
• Q-DIMM
• Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
• Q-Slot

ASUS Thermal Solution

• M.2 heatsink
• VRM heatsink design

ASUS EZ DIY

• BIOS FlashBack button
• BIOS FlashBack LED
• Clear CMOS button
• ProCool
• Pre-mounted I/O shield
• SafeSlot
• SafeDIMM

Aura Sync

• Aura RGB headers
• Addressable Gen 2 headers

ASUS Exclusive Software

• Armoury Crate
  Aura Sync
  Fan Xpert 4 with AI Cooling II
  Power Saving
  Two-Way AI Noise Cancelation

AI Suite 3

• Easy Optimization

• DIGI+ VRM
• Turbo app
• PC Cleaner

ASUS CPU-Z

DTS:X Ultra

MyAsus

Norton Anti-virus software (Free Trial version)

WinRAR

UEFI BIOS

ASUS EZ DIY

• ASUS CrashFree BIOS 3
• ASUS EZ Flash 3
• ASUS UEFI BIOS EZ Mode

FlexKey

MemTest86

• Support for Windows 11 64-bit

• ATX Form Factor, 30.5cm x 24.4cm
