The Elite 500 is the essential solution for optimized cooling. Substantial ventilation on the front panel allows fresh air into the system for both air-cooled and liquid cooled configurations. For simple tasks, the Elite 500 is a cost-effective solution to professional computing. For higher-demand tasks, the Elite 500 boasts a high compatibility for upgrades, able to house liquid cooling and provides clearance for the longest, widest graphics cards. The front panel is constructed with a substantially large, unrestricted intake grill to provide superb airflow to the system. Depending on preference, an ODD version of the chassis is available. If an ODD is not preferred, a cleaner appearance and more cooling options on the top and front panels are supported. The ODD version of the Elite 500 is slightly deeper in comparison to its non-ODD counterpart. Support for up to six fans and front, top, and rear radiator support ensure that performance is not compromised. Let your system stand out with an all-black background and a PSU cover to hide cables. The PSU cover is ventilated on top of the power supply location, this allows actively cooled units to be installed either with the fan facing the top or bottom, also with the possibility of installing passively cooled power supplies. Support for up to a 400mm graphics card, a 161mm CPU cooler, and multiple fans/radiators locations provides room for upgrades to stay ahead of the game. The single 4 pole headset jack features both Audio and Microphone capabilities simultaneously so that separate jacks are not needed. The HDD cage is (re)movable. The cage can be shifted forward to make room for a longer PSU, backwards for additional radiator space, or completely removed if HDD storage is not needed.

Model	E500-KN5N-S00
Colour	Black
Lighting	None
Materials	Steel, Plastic
Dimensions	464mm x 204mm x 455mm
Form Factor	Mid Tower
Motherboard Support	ATX, Micro ATX, Mini ITX
Front I/O	2 x USB 3.2 Gen 1 1 x Headphone Out / Mic In Combo 1 x Power Button 1 x Reset Button
Side Panel	Solid
Drive Bays	5.25": 1 3.5" / 2.5" Combo: 2 3.5": 0 2.5": 5
Expansion Slots	7
Fan Support	Front: 2 x 120mm / 2 x 140mm Top: 2 x 120mm / 2 x 140mm Back: 1 x 120mm Bottom: None Side: None
Radiator Support	Front: 280mm (remove ODD) / 240mm (remove ODD) / 140mm / 120mm Top: 240mm / 120mm Back: 120mm Bottom: None Side: None
Clearances	CPU Cooler: 163mm GPU Length: 400mm without front fans/radiator PSU Length: 180mm
Weight	Not Specified
