• Support for Intel Core i7-7800X and above X series processors/Intel Core i9 X series processors in the LGA2066 package

• L3 cache varies with CPU

• Intel X299 Express Chipset


• Intel Core X series 48-lane processors:
  8 x DDR4 DIMM sockets supporting up to 256 GB (32 GB single DIMM capacity) of system memory
  Support for DDR4 4333(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933/2666/2400/2133 MHz memory modules
• Intel Core X series 44-lane/28-lane processors:
  8 x DDR4 DIMM sockets supporting up to 128 GB (16 GB single DIMM capacity) of system memory
  Support for DDR4 4200(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2666/2400/2133 MHz memory modules
• 4 channel memory architecture
• Support for non-ECC Un-buffered DIMM memory modules
• Support for Extreme Memory Profile (XMP) memory modules

• None

• Realtek ALC1220-VB codec
  * The front panel line out jack supports DSD audio.
• ESS SABRE9218 DAC chip

• High Definition Audio
• 2/4/5.1/7.1-channel

• Support for S/PDIF Out


• 1 x Aquantia 5GbE LAN chip (5 Gbit/2.5 Gbit/1000 Mbit/100 Mbit) (LAN1)

• 1 x Intel GbE LAN chip (10/100/1000 Mbit) (LAN2)

• Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band

• BLUETOOTH 5.0
• Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
  * Actual data rate may vary depending on environment and equipment.

• Intel Core X series 48-lane processors:
  2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
  2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)
  * The PCIEX16_2 slot shares bandwidth with the PCIEX8_1 slot. When the PCIEX8_1 slot is populated, the PCIEX16_2 slot operates at up to x8 mode.
• Intel Core X series 44-lane processors:
  2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
  1 x PCI Express x16 slot, running at x8 (PCIEX8_1)
  1 x PCI Express x16 slot, running at x4 (PCIEX8_2)
  * The PCIEX16_2 slot shares bandwidth with the PCIEX8_1 slot. When the PCIEX8_1 slot is populated, the PCIEX16_2 slot operates at up to x8 mode.
• Intel Core X series 28-lane processors:
  1 x PCI Express x16 slot, running at x16 (PCIEX16_1)
  1 x PCI Express x16 slot, running at x8 (PCIEX16_2)
  1 x PCI Express x16 slot, running at x4 (PCIEX8_2)
  * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16_1 slot.
• (All of the PCI Express x16 slots conform to PCI Express 3.0 standard.)

• Support for NVIDIA Quad-GPU SLI and 2-Way NVIDIA SLI technologies

• Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies

CPU:

• 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe x4/x2 SSD support) (M2M)
• 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2Q)
• * The M2M and M2Q connectors become unavailable when an Intel Core X series 28-lane processor is used.

Chipset:

• 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2P)
• 8 x SATA 6Gb/s connectors
• Support for RAID 0, RAID 1, RAID 5, and RAID 10
• The M2M and M2Q connectors must work with an Intel VROC Upgrade Key to support RAID configuration. If you want to use VROC, refer to Chapter 3-4, "Configuring Intel® Virtual RAID on CPU (Intel VROC)," for setup instructions.
  * Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

Intel Optane Memory Ready

• * Only Intel Core X series 48-lane processors support Intel Optane™ Memory.
• Intel VROC Ready

Chipset+2 ASMedia USB 3.2 Gen 2 Controllers:

• 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header
• 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support
• 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel

Chipset+Realtek USB 3.2 Gen 1 Hub:

• 2 x USB 3.2 Gen 1 ports on the back panel
• 2 x USB 2.0/1.1 ports on the back panel

Chipset+USB 2.0 Hub:

• 4 x USB 2.0/1.1 ports available through the internal USB headers

Chipset:

• 8 x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
• 2 x USB 2.0/1.1 ports available through the internal USB header

• 1 x 24-pin ATX main power connector

• 2 x 8-pin ATX 12V power connectors
• 1 x CPU fan header
• 1 x water cooling CPU fan header
• 4 x system fan headers
• 2 x system fan/water cooling pump headers
• 2 x addressable LED strip headers
• 2 x RGB LED strip headers
• 3 x M.2 Socket 3 connectors
• 8 x SATA 6Gb/s connectors
• 1 x Intel VROC Upgrade Key header
• 1 x front panel header
• 1 x front panel audio header
• 1 x USB Type-C port, with USB 3.2 Gen 2 support
• 2 x USB 3.2 Gen 1 headers
• 3 x USB 2.0/1.1 headers
• 1 x noise detection header
• 1 x Thunderbolt add-in card connector
• 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
• 1 x power button
• 1 x reset button
• 2 x temperature sensor headers
• 1 x Clear CMOS jumper
• 2 x BIOS switches

• 1 x Q-Flash Plus button

• 1 x Clear CMOS button
• 1 x USB Type-C port, with USB 3.2 Gen 2 support
• 1 x USB 3.2 Gen 2 Type-A port (red)
• 6 x USB 3.2 Gen 1 ports
• 2 x USB 2.0/1.1 ports
• 2 x RJ-45 ports
• 2 x SMA antenna connectors (2T2R)
• 1 x optical S/PDIF Out connector
• 5 x audio jacks

• iTE I/O Controller Chip

• Voltage detection
• Temperature detection
• Fan speed detection
• Water cooling flow rate detection
• Overheating warning
• Fan fail warning
• Fan speed control
  * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
• Noise detection

• 2 x 128 Mbit flash
• Use of licensed AMI UEFI BIOS
• Support for DualBIOS
• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

• Support for APP Center
  * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
  @BIOS
  AutoGreen
  Cloud Station
  EasyTune
  Easy RAID
  Fast Boot
  Game Boost
  Platform Power Management
  RGB Fusion
  Smart Backup
  Smart Keyboard
  Smart Survey
  System Information Viewer
  USB Blocker
  USB TurboCharger
• Support for Q-Flash Plus
• Support for Q-Flash
• Support for Xpress Install


• Norton Internet Security (OEM version)
• cFosSpeed
• XSplit Gamecaster + Broadcaster (12 months license)

• Support for Windows 10 64-bit

• E-ATX Form Factor, 30.5cm x 26.9cm
