AMD Socket AM5

• Supports AMD Ryzen 7000 / 8000 / 9000 Series Desktop Processors

4 x DDR5 DIMM sockets supporting up to 256 GB of system memory

• Dual Channel DDR5 Memory Technology

• Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC)
• Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules

Integrated AMD RDNA graphics

• 1 x HDMI 2.1 TMDS/FRL 8G Compatible

• Supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
• 2 x USB4
• Support HDCP 2.3 and max. resolution up to 8K 30Hz
• USB4 Type-C ports on the rear panel and PCIE3 slot share PCIe Gen4x4 bandwidth. Both run at PCIe Gen4x2 when PCIE3 slot is occupied. You can switch PCIE3 to PCIe Gen4x4 in the BIOS, but this will disable the USB4 Type-C ports. The USB4 host controller supports up to PCIe Gen4x4

7.1 CH HD Audio (Realtek ALC897 Audio Codec)

• Nahimic Audio


2.5 Gigabit LAN 10/100/1000/2500 Mb/s

• Dragon RTL8125BG

• Supports Dragon 2.5G LAN Software
• Smart Auto Adjust Bandwidth Control
• Visual User Friendly UI
• Visual Network Usage Statistics
• Optimized Default Setting for Game, Browser, and Streaming Modes
• User Customized Priority Control

802.11be 2x2 Wi-Fi 7 Module

• Supports IEEE 802.11a/b/g/n/ac/ax/axe/be
• Supports 2.4GHz/5GHz/6GHz frequency band
• Supports 160MHz channel bandwidth with 6GHz frequency band
• 1 antenna to support 2 (Transmit) x 2 (Receive) diversity technology
• Supports MU-MIMO

Supports Bluetooth 5.4

CPU:

• 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode
• 1 x PCIe 4.0 x16 Slot (PCIE3), supports x4 mode
• USB4 Type-C ports on the rear panel and PCIE3 slot share PCIe Gen4x4 bandwidth. Both run at PCIe Gen4x2 when PCIE3 slot is occupied. You can switch PCIE3 to PCIe Gen4x4 in the BIOS, but this will disable the USB4 Type-C ports. The USB4 host controller supports up to PCIe Gen4x4.


Chipset:

• 1 x PCIe 4.0 x16 Slot (PCIE2), supports x1 mode

• PCIE1 will run at Gen5x16 with 9000 and 7000 series processors, Gen4x8 with 8000 (Phoenix 1) series processors and Gen4x4 with 8000 (Phoenix 2) series processors.

• 1 x PCIe 4.0 x16 Slot (PCIE4), supports x1 mode
• PCIE1 will run at Gen5x16 with 9000 and 7000 series processors, Gen4x8 with 8000 (Phoenix 1) series processors and Gen4x4 with 8000 (Phoenix 2) series processors.

• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module

CPU:

• 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode
• M2_1 is the first priority for M.2 installation
• M2_1 will run at Gen5x4 with 9000 and 7000 series processors and Gen4x4 with 8000 (Phoenix 1 and Phoenix 2) series processors

Chipset:

• 1 x M.2 Socket (M2_2, Key M), supports type 2280 SATA3 6.0 Gb/s & PCIe Gen3x2 (16 Gb/s) modes

• 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode

• If M2_2 is occupied, SATA3_3 and SATA3_4 will be disabled.
• 4 x SATA3 6.0 Gb/s Connectors

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices

Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices

• Requires additional M.2 NVMe expansion cards to support RAID 10

CPU:

• 2 x USB4 Type-C (Rear)
• 2 x USB 3.2 Gen2 Type-A (Rear)


Chipset:

• 1 x USB 3.2 Gen1 Type-C (Front)

• 5 x USB 3.2 Gen1 Type-A (1 Rear, 4 Front)
• 8 x USB 2.0 (4 Rear, 4 Front)

All USB ports support ESD Protection

• 1 x SPI TPM Header

• 1 x Power LED and Speaker Header
• 1 x RGB LED Header
• Supports in total up to 12V/3A, 36W LED Strip
• 3 x Addressable LED Headers
• Support in total up to 5V/3A, 15W LED Strip
• 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control)
• CPU_FAN1 supports the fan power up to 1A (12W).
• CPU_FAN2, CHA_FAN1~3 and AIO_PUMP support the fan power up to 3A (36W).
• CPU_FAN2, CHA_FAN1~3 and AIO_PUMP can auto detect if 3-pin or 4-pin fan is in use.
• 3 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)
• CPU_FAN1 supports the fan power up to 1A (12W).
• CPU_FAN2, CHA_FAN1~3 and AIO_PUMP support the fan power up to 3A (36W).
• CPU_FAN2, CHA_FAN1~3 and AIO_PUMP can auto detect if 3-pin or 4-pin fan is in use.
• 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)
• CPU_FAN1 supports the fan power up to 1A (12W).
• CPU_FAN2, CHA_FAN1~3 and AIO_PUMP support the fan power up to 3A (36W).
• CPU_FAN2, CHA_FAN1~3 and AIO_PUMP can auto detect if 3-pin or 4-pin fan is in use.
• 1 x 24 pin ATX Power Connector
• 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
• 1 x Front Panel Audio Connector
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
• 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
• 1 x Front Panel Type C USB 3.2 Gen1 Header

• 2 x Antenna Ports

• 1 x HDMI Port
• 2 x USB4 Type-C Ports (40 Gb/s)
• Supports USB PD 3.0 up to 5V@3A (15W) charging

• 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s)
• 1 x USB 3.2 Gen1 Type-A Port
• 4 x USB 2.0 Ports
• 1 x RJ-45 LAN Port
• 1 x BIOS Flashback Button
• HD Audio Jacks: Line in / Front Speaker / Microphone

Not Specified

• Voltage detection

• Temperature detection
• Fan speed detection
• Water cooling flow rate detection

• Fan fail warning
• Fan speed control

1 x 256 Mbit flash

• AMI UEFI Legal BIOS with GUI support


Superb Productivity

• PCIe Gen5 (Graphics, M.2)
• Dual Channel DDR5
• USB4 Type-C Ports (40 Gb/s)

Rock-Solid Durability

• 16+2+1 Power Phase, 80A Dr.MOS for VCore+SOC+MISC with Enlarged Heatsink Armor
• Flexible Integrated I/O Shield

Ultrafast Connectivity

• 2.5G LAN, 802.11be Wi-Fi 7 Module


EZ Update

• BIOS Flashback Button
• ASRock Auto Driver Installer

EZ Troubleshooter

• ASRock Post Status Checker

Software

• ASRock Motherboard Utility (A-Tuning)

• ASRock Dragon 2.5G LAN Software
• ASRock Polychrome SYNC
• These utilities can be downloaded from ASRock Live Update & APP Shop

UEFI

• ASRock EZ Mode
• ASRock Full HD UEFI
• ASRock Auto Driver Installer
• ASRock Instant Flash

Support for Windows 11 64-bit

ATX Form Factor

• 30.5cm x 24.4cm
