• AMD Socket AM4, Supports AMD Ryzen 5000 Series / Ryzen 5000 G-Series / 3rd Gen Ryzen/ 2nd Gen Ryzen/ 3rd Gen Ryzen with Radeon Graphics/ 2nd Gen Ryzen with Radeon Vega Graphics/ 1st Gen Ryzen with Radeon Vega Graphics Processors


• AMD X570


• AMD Ryzen 5000 series processors:
  Support for DDR4 5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.)/ 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
• 3rd Generation AMD Ryzen processors:
  Support for DDR4 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.)/ 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
• 3rd Generation AMD Ryzen with Radeon Graphics processors:
  Support for DDR4 5400(O.C.)/ 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.)/ 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
• 2nd Generation AMD Ryzen processors/ 2nd Generation AMD Ryzen with Radeon Vega Graphics processors / 1st Generation AMD Ryzen with Radeon Vega Graphics processors:
  Support for DDR4 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
• 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
• Dual channel memory architecture
• Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
• Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
• Support for Extreme Memory Profile (XMP) memory modules

Integrated Graphics Processor

• 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
  * Support for HDMI 2.0 version, HDCP 2.2, and HDR.
• Maximum shared memory of 16 GB
  * For 2nd Generation AMD Ryzen with Radeon™ Vega Graphics processors/AMD Ryzen with Radeon Vega Graphics processors only.

• Realtek ALC1220-VB codec
  * The front panel line out jack supports DSD audio
• High Definition Audio
• 2/4/5.1/7.1-channel
• Support for S/PDIF Out

• Intel GbE LAN chip (10/100/1000 Mbit)


• Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band

• BLUETOOTH 5.0
• Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
  * Actual data rate may vary depending on environment and equipment.

Integrated in the CPU (PCIEX16/PCIEX8):

• 3rd Generation AMD Ryzen processors:
  1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
  1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x8 (PCIEX8)
• 2nd Generation AMD Ryzen processors/3rd Generation AMD Ryzen with Radeon Graphics processors:
  1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 (PCIEX16)
  1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 (PCIEX8)
  * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
  * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When using the 3rd Generation AMD Ryzen processors/2nd Generation AMD Ryzen processors and PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
• 2nd Generation AMD Ryzen with Radeon Vega Graphics processors/1st Generation AMD Ryzen with Radeon Vega Graphics processors:
  1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 (PCIEX16)

Integrated in the Chipset (PCIEX4/PCIEX1):

• 1 x PCI Express x16 slot, supporting PCIe 4.0/3.0 and running at x4 (PCIEX4)
  * For 3rd Generation AMD Ryzen processors only.
• 2 x PCI Express x1 slots, supporting PCIe 4.0/3.0
  * For 3rd Generation AMD Ryzen processors only.

• Support for NVIDIA Quad-GPU SLI and 2-Way NVIDIA SLI technologies

• Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies

* For 3rd Generation AMD Ryzen processors/2nd Generation AMD Ryzen processors/3rd Generation AMD Ryzen with Radeon Graphics processors only.

Integrated in the CPU (M2A_SOCKET):

• 3rd Generation AMD Ryzen processors:
  1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support)
• 2nd Generation AMD Ryzen processors/3rd Generation AMD Ryzen with Radeon Graphics processors/2nd Generation AMD Ryzen with Radeon Vega Graphics processors/1st Generation AMD Ryzen with Radeon Vega Graphics processors:
  1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support)

Integrated in the Chipset (M2B_SOCKET/M2C_SOCKET):

• 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0*/3.0 x4/x2 SSD support) (M2B_SOCKET)
  * For 3rd Generation AMD Ryzen processors only.
• 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 4.0*/3.0 x2 SSD support) (M2C_SOCKET)
  * For 3rd Generation AMD Ryzen processors only.
• 6 x SATA 6Gb/s connectors
• Support for RAID 0, RAID 1, and RAID 10
• * Refer to "1-8 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

• 3 x USB 3.2 Gen 1 ports on the back panel
• 1 x USB 3.2 Gen 2/Gen 1 Type-A port (red) on the back panel
  * Gen 2 for 3rd Generation AMD Ryzen processors only.

• 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header
• 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support
• 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
• 4 x USB 3.2 Gen 1 ports available through the internal USB headers

• 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

• 1 x 24-pin ATX main power connector

• 1 x 8-pin ATX 12V power connector
• 1 x 4-pin ATX 12V power connector
• 1 x CPU fan header
• 1 x water cooling CPU fan header
• 3 x system fan headers
• 2 x system fan/water cooling pump headers
• 2 x addressable LED strip headers
• 2 x RGB LED strip headers
• 1 x CPU cooler LED strip/RGB LED strip header
• 3 x M.2 Socket 3 connectors
• 6 x SATA 6Gb/s connectors
• 1 x front panel header
• 1 x front panel audio header
• 1 x USB Type-C port, with USB 3.2 Gen 2 support
• 2 x USB 3.2 Gen 1 headers
• 2 x USB 2.0/1.1 headers
• 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
• 1 x Thunderbolt add-in card connector
• 1 x Clear CMOS jumper
• 2 x temperature sensor headers
• 1 x Q-Flash Plus button
  ＊ All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24W.

• 2 x SMA antenna connectors (2T2R)

• 1 x HDMI port
• 1 x USB Type-C port, with USB 3.2 Gen 2 support
• 1 x USB 3.2 Gen 2*/Gen 1 Type-A port (red)
  * For 3rd Generation AMD Ryzen processors only.
• 1 x USB 3.2 Gen 2 Type-A port (red)
• 3 x USB 3.2 Gen 1 ports
• 4 x USB 2.0/1.1 ports
• 1 x RJ-45 port
• 1 x optical S/PDIF Out connector
• 5 x audio jacks

• iTE I/O Controller Chip

• Voltage detection
• Temperature detection
• Fan speed detection
• Water cooling flow rate detection
• Overheating warning
• Fan fail warning
• Fan speed control
  * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

• 2 x 128 Mbit flash
• Use of licensed AMI UEFI BIOS
• Support for DualBIOS
• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

• Support for APP Center
  * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
  @BIOS
  EasyTune
  Fast Boot
  Game Boost
  ON/OFF Charge
  RGB Fusion
  Smart Backup
  System Information Viewer

• Support for Q-Flash Plus
• Support for Q-Flash
• Support for Xpress Install


• Norton Internet Security (OEM version)
• cFosSpeed
• XSplit Gamecaster + Broadcaster (12 months license)

• Support for Windows 10 64-bit

• ATX Form Factor, 30.5cm x 24.4cm
