• Intel Socket LGA1200 for 11th Gen Intel Core processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors

• Supports Intel 14 nm CPU
• Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0

• Intel Z590 Express Chipset


• 4 x DIMM, Max. 128GB, DDR4

• DDR4 5333(OC) / 5133(OC) / 5000(OC) / 4800(OC) / 4700(OC) / 4600(OC) / 4500(OC) / 4400(OC) / 4266(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3333(OC) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz Non-ECC, Un-buffered Memory
• Dual Channel Memory Architecture
• Supports Intel Extreme Memory Profile (XMP)
• OptiMem II
• 10th Gen Intel Core i7/i9 processors support 2933 / 2800 / 2666 / 2400 /2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz.
• 11th Gen Intel Core processors support 3200 / 2933 / 2800 / 2666 / 2400 / 2133 natively.

Integrated Graphics Processor:

• 1 x DisplayPort 1.4

• 1 x HDMI 2.0
  *Graphics specifications may vary between CPU types.
  *Only Intel 11th Core processors support DisplayPort 1.4 with max. resolution of 5120 x 2880 @60Hz, others will only support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any updates
  *Only Intel 11th Core processors, support HDMI 2.0 with max. resolution of 4K@60Hz, others would only support HDMI 1.4 with max. resolution of 4K@30Hz. Please refer to www.intel.com for any update.
  *VGA resolution support depends on processors' or graphic cards' resolution.

• Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC
  Impedance sense for front and rear headphone outputs
  Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
  Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
  High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
  Supports up to 32-Bit/192 kHz playback
  * Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio
• Audio Features:
  Power pre-regulator reduces power input noise to ensure consistent performance
  Rear optical S/PDIF out port
  Premium Japanese audio capacitors
  Audio Shielding
  Dedicated audio PCB layers
  Audio cover
  Unique de-pop circuit

• 1 x Intel I225-V 2.5Gb Ethernet

• None


Intel 11th & 10th Gen Processors

• 3 x PCIe 4.0/3.0 x16 slots
  Intel 11th Core processors support PCIe 4.0 x16
  Intel 10th processors support PCIe 3.0 x16
  * Supports PCIe bandwidth bifurcation for RAID on CPU function.

Intel Z590 Chipset

• 1 x PCIe 3.0 x4 slot

• N/A


Total supports 3 x M.2 slots and 6 x SATA 6Gb/s ports

Intel 11th Gen Processors

• M.2_1 slot (Key M), type 2242/2260/2280/22110
  Only Intel 11th Core processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs

Intel Z590 Chipset

• M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)
• M.2_3 slot (Key M), type 2242/2260/22110 (supports PCIe 3.0 x4 & SATA modes)
• 6 x SATA 6Gb/s ports
  Raid function for PCIe mode SSD in Intel Rapid Storage Technology is available with either 1. Intel SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots.
  To enable Intel Optane Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel Rapid Storage Technology.
  M.2_2 shares bandwidth with SATA6G_2. When M.2_2 runs SATA mode, SATA6G_2 will be disabled.
  M.2_3 shares bandwidth with SATA6G_6. When M.2_6 runs SATA mode, SATA6G_6 will be disabled.

Rear USB (Total 9 ports)

• 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
• 4 x USB 3.2 Gen 2 ports (3 x Type-A, 1 x Type-C)
• 4 x USB 2.0 ports (4 x Type-A)

Front USB (Total 7 ports)

• 1 x USB 3.2 Gen 1 connector (supports USB Type-C)
• 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
• 2 x USB 2.0 headers support additional 4 USB 2.0 ports

• Fan and Cooling related
  1 x 4-pin CPU Fan header
  1 x 4-pin CPU OPT Fan header
  1 x 4-pin AIO Pump header
  3 x 4-pin Chassis Fan headers
  1 x 4-pin VRM_HS Fan header
  1 x W_PUMP+ header
• Power related
  1 x 24-pin Main Power connector
  1 x 8-pin +12V Power connector
  1 x 4-pin +12V Power connector
• Storage related
  3 x M.2 slots (Key M)
  6 x SATA 6Gb/s ports
• USB
  1 x USB 3.2 Gen 1 connector (supports USB Type-C®)
  1 x USB 3.2 Gen 1 headers supports additional 2 USB 3.2 Gen 1 ports
  2 x USB 2.0 headers support additional 4 USB 2.0 ports
• Miscellaneous
  3 x AURA Addressable Gen 2 headers
  1 x AURA RGB headers
  1 x Clear CMOS header
  1 x COM Port header
  1 x Front Panel Audio header (AAFP)
  1 x CPU Over Voltage jumper
  1 x Power button
  1 x SPI TPM header (14-1pin)
  1 x 20-3 pin System Panel header with Chassis intrude function
  1 x Thermal Sensor header
  1 x Thunderbolt header

• 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)

• 4 x USB 3.2 Gen 2 ports (3 x Type-A, 1 x Type-C)
• 4 x USB 2.0 ports (4 x Type-A)
• 1 x DisplayPort
• 1 x HDMI port
• 1 x Intel I225-V 2.5Gb Ethernet port
• 5 x Audio jacks
• 1 x Optical S/PDIF out port

• N/A

• Voltage detection
• Temperature detection
• Fan speed detection
• Overheating warning
• Fan fail warning
• Fan speed control
  * Whether the fan speed control function is supported will depend on the fan you install.

• 256 Mb Flash ROM, UEFI AMI BIOS


• ASUS 5X PROTECTION III
  ASUS DIGI+ VRM (- Digital power design with Dr. MOS)
  ASUS Enhanced DRAM Overcurrent Protection
  ASUS ESD Guards
  ASUS LANGuard
  ASUS Overvoltage Protection
  ASUS Stainless-Steel Back I/O
• ASUS Q-Design
  M.2 Q-Latch
  ASUS Q-Connector
  ASUS Q-DIMM
  ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow-green])
  ASUS Q-Slot
• ASUS Thermal Solution
  Aluminum M.2 Heatsink
  Flexible M.2 heatsink
• ASUS EZ DIY
  Procool
  Pre-mounted I/O shield
  ASUS SafeSlot
• ASUS Exclusive Software
• Armoury Crate
  Aura Creator
  Aura Sync
  Two-Way AI Noise Cancelation
• AI Suite 3
  5-way Optimization with AI Overclocking
• TPU
• EPU
• Digi+ VRM
• Fan Xpert 4
• Turbo app
  EZ update
• AI Charger
• ASUS CPU-Z
• ASUS Turbo LAN
• MyAsus
• DTS:X Ultra
• UEFI BIOS
• AI Overclocking Guide
• ASUS EZ DIY
  ASUS CrashFree BIOS 3
  ASUS EZ Flash 3
  ASUS UEFI BIOS EZ Mode
  EZ Tuning Wizard
• FlexKey

• Driver and software disc

• Windows 10 64-bit

• ATX Form Factor, 30.5cm x 24.4cm
