• Intel Socket LGA1200 for 11th Gen Intel Core Processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors

• Supports Intel 14 nm CPU
• Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0

• Intel Z590 Express Chipset


• 4 x DIMM, Max. 128GB
• 5333(OC) / 5133(OC) / 5000(OC) / 4800(OC) / 4700(OC) / 4600(OC) / 4500(OC) / 4400(OC) / 4266(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
• Dual Channel Memory Architecture
• Supports Intel Extreme Memory Profile (XMP)
• OptiMem III

Integrated Graphics Processor:

• 2 x HDMI 2.0

• 2 x Intel Thunderbolt 4 ports
• 1 x HDMI 1.4 / 2.0
• 2 x HDMI 2.0
• 2 x Intel Thunderbolt 4 ports (USB Type-C) support DisplayPort 1.2/1.4 and Thunderbolt video outputs
  * Graphics specifications may vary between CPU types.
  * Only Intel 11th Core processors support HDMI 2.0 with max. resolution of 4K@60Hz, others will only support HDMI 1.4 with max. resolution of 4K@30Hz

• ALC4082
  SupremeFX Shielding Technology
  ESS SABRE9018Q2C DAC/AMP
  Gold-plated audio jacks
  Rear optical S/PDIF out port
  Premium Japanese audio capacitors
  Audio cover

• 2 x Intel I225-V 2.5Gb Ethernet

• ASUS LANGuard

• 2x2 Tri-Band Intel Wi-Fi a/b/g/n/ac/ax/az + BT5.2


• 2 x PCIe 4.0/3.0 x16 slot(s)
• Intel 11th Core processors support PCIe 4.0 x16 or x8/x8 or x8/x4 mode(s)
• Intel 10th Core processors support PCIe 3.0 x16 or x8/x8 or x8/x4 mode(s)

• 1 x PCIe 3.0 x16 slot (supports x4 mode)
• 1 x PCIe 3.0 x1 slots
• Supports PCIe bandwidth bifurcation for RAID on CPU function.
• PCIEX16_3 shares bandwidth with SATA6G_12 and SATA6G_34. When PCIEX16_ 3 is populated SATA6G_12 and SATA6G_34 will be disabled.
• When PCIEX16_3 run at default (x2) mode, SATA6G_34 is disabled.
• When PCIEX16_3 run at x4 mode, SATA6G_12 and SATA6G_34 are disabled.

• Supports NVIDIA 2-Way SLI Technology


Supports 4 x M.2 slots and 6 x SATA 6Gb/s ports

Intel 11th & 10th Gen Processors

• M.2_1 slot (Key M), type 2242/2260/2280/22110
• Only Intel 11th Core processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs
• M.2_2 slot (Key M), type 2242/2260/2280
• Intel 11th Core processors support PCIe 4.0 x4 mode
• Intel 10th Core processors support PCIe 3.0 x4 mode

Intel Z590 Chipset

• M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)
• M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)
• 6 x SATA 6Gb/s ports

Raid function for PCIe mode SSD in Intel Rapid Storage Technology is available with either 1. Intel SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots.

To enable Intel Optane Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel Rapid Storage Technology.

When M.2_4 is populated, SATA6G_56 will be disabled.

M.2_2 shares bandwidth with PCIEX16_1 and PCIEX16_2. When M.2_2 is enabled, PCIEX16_1 will run at x8 mode and PCIEX16_2 will run at x4 mode.

Rear USB Port ( Total 10 )

• 2 x Thunderbolt 4 port(s) (2 x USB Type-C) with up to 5V/3A, 15W charging support

• 6 x USB 3.2 Gen 2 port(s) (6 x Type-A)
• 2 x USB 2.0 port(s) (2 x Type-A)

Front USB Port ( Total 9 )

• 1 x USB 3.2 Gen 2x2 connector(s) (suppport(s) USB Type-C)

• 2 x USB 3.2 Gen 1 header(s) support(s) additional 4 USB 3.2 Gen 1 ports
• 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports

• 2 x Thunderbolt  4 port(s) (2 x USB Type-C) with up to 5V/3A, 15W charging support

• Fan and Cooling related
  1 x 4-pin CPU Fan header(s)
  1 x 4-pin CPU OPT Fan header(s)
  1 x 4-pin AIO Pump header(s)
  3 x 4-pin Chassis Fan header(s)
  1 x 4-pin H_AMP Fan header(s)
  1 x W_PUMP+ header(s)
  1 x 2-pin Water In header
  1 x 2-pin Water Out header
  1 x 3-pin Water Flow header
• Power related
  1 x 24-pin Main Power connector
  2 x 8-pin +12V Power connector
• Storage related
  4 x M.2 slots (Key M)
  6 x SATA 6Gb/s ports
• USB
  1 x USB 3.2 Gen 2x2 connector (support(s) USB Type-C)
  2 x USB 3.2 Gen 1 header(s) support(s) additional 4 USB 3.2 Gen 1 ports
  2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports
• Miscellaneous
  3 x AURA Addressable Gen 2 header(s)
  1 x AURA RGB header(s)
  1 x FlexKey button
  1 x Front Panel Audio header (AAFP)
  1 x ReTry button
  1 x Speaker header
  1 x SPI TPM header (14-1pin)
  1 x Start button
  1 x 10-1 pin System Panel header
  1 x Thermal Sensor header

• 2 x Thunderbolt 4 USB Type-C port(s)

• 6 x USB 3.2 Gen 2 port(s) (6 x Type-A)
• 2 x USB 2.0 port(s) (2 x Type-A)
• 1 x HDMI port
• 1 x ASUS Wi-Fi Module
• 2 x Intel I225-V 2.5Gb Ethernet
• 5 x Gold-plated audio jacks
• 1 x Optical S/PDIF out port
• 1 x BIOS FlashBack  button
• 1 x Clear CMOS button

• N/A

• Voltage detection
• Temperature detection
• Fan speed detection
• Overheating warning
• Fan fail warning
• Fan speed control
  * Whether the fan speed control function is supported will depend on the fan you install.

• 256 Mb Flash ROM, UEFI AMI BIOS


• Extreme OC Kit
  FlexKey button
  ReTry button
  Start button
• Extreme Engine Digi+
  10K Black Metallic Capacitors
  MicroFine Alloy Choke
• ASUS Q-Design
  Q-Code
  Q-Connector
  Q-DIMM
  Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
  Q-Slot
• ASUS Thermal Solution
  M.2 heatsink backplate
  M.2 heatsink
  VRM heatsink design
• ASUS EZ DIY
  BIOS FlashBack button
  Clear CMOS button
  ProCool II
  Pre-mounted I/O shield
  SafeSlot
• AURA Sync
  AURA RGB header(s)
  Addressable Gen 2 RGB header(s)
• ASUS HYDRANODE
  3 x Chassis fan support (CHA_FAN1P,CHA_FAN2P,CHA_FAN3P)

• Driver and software disc

• Windows 10 64-bit

• ATX Form Factor, 30.5cm x 24.4cm
