• Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold and Celeron Processors

• Supports Intel 14 nm CPU
• Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
  * The Intel Turbo Boost Technology 3.0 support depends on the CPU types.

• Intel Z490 Express Chipset


• 2 x DIMM, Max. 64GB, DDR4 4800(O.C.) / 4600(O.C) / 4500(O.C) / 4400(O.C) / 4333(O.C.) 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3200(O.C.) / 3000 / 2933 / 2800(O.C.) / 2666 / 2400 / 2133 MHz Non-ECC, Un-buffered Memory

• Dual Channel Memory Architecture
• Supports Intel Extreme Memory Profile (XMP)
• OptiMem II

Integrated Graphics Processor

• 1 x DisplayPort 1.4
  * Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz
• 1 x HDMI 2.0a

• ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
  Dual OP Amplifiers
  Impedance sense for front and rear headphone outputs
  Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
  Supports up to 32-Bit/192kHz playback
  LED-illuminated audio jacks
• Audio Feature:
  Audio Shielding
  Premium Japanese audio capacitors
  * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
  * Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.

• Intel I225-V 2.5Gb Ethernet

• ASUS LANGuard

• Intel Wi-Fi 6 AX201
  2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO
  Supports up to 2.4Gbps max data rate
  Supports dual band frequency 2.4/5 GHz
  Supports channel bandwidth: HT20/HT40/HT80/HT160
  Supports CNVI interface
• Bluetooth v5.1
  *BT 5.1 function will be ready in Windows 10 build 19041 or later.

Intel 10th Gen Processors

• 1 x PCIe 3.0 x16
  * Support PCIe bifurcation for RAID on CPU function.

• N/A

Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports

Intel Z490 Chipset:

• 1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support

• 1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support
  * When the M.2_2 Socket is operating in SATA mode, SATA port 2 will be disabled.
• 4 x SATA 6Gb/s port(s)
• Support Raid 0, 1, 5, 10
• Intel Optane Memory Ready

Rear USB Port ( Total 8 )

• 4 x USB 3.2 Gen 2 port(s)(3 x Type-A +1 x USB Type-C)
• 2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
• 2 x USB 2.0 port(s)(2 x Type-A)

Front USB Port ( Total 5 )

• 1 x USB 3.2 Gen 2 front panel connector port(s)
• 2 x USB 3.2 Gen 1 port(s)
• 2 x USB 2.0 port(s)

• 1 x CPU Fan connector(s)

• 1 x Chassis Fan connector(s)
• 1 x AIO_PUMP connector
• 1 x Aura RGB Strip Header
• 1 x Addressable Gen 2 header(s)
• 1 x M.2 Socket 1 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
• 1 x M.2 Socket 2 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
• 4 x SATA 6Gb/s connector(s)
• 1 x 24-pin EATX Power connector(s)
• 1 x 8-pin ATX 12V Power connector(s)
• 1 x Front panel audio connector(s) (AAFP)
• 1 x Internal speaker connector(s)
• 1 x System panel(s) (Chassis intrusion header is inbuilt)
• 1 x Clear CMOS jumper(s)
• 1 x Thermal sensor connector
• 1 x USB 3.2 Gen 2 front panel connector
• 1 x USB 3.2 Gen 1 connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
• 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)

• 1 x Intel I225-V 2.5Gb Ethernet

• 1 x DisplayPort
• 1 x HDMI
• 4 x USB 3.2 Gen 2 (3 x Type-A+1 x USB Type-C)
• 2 x USB 3.2 Gen 1 Type-A
• 2 x USB 2.0 (one port can be switched to USB BIOS FlashBack)
• 1 x USB BIOS FlashBack™ Button(s)
• 1 x ASUS Wi-Fi Module
• 3 x LED-illuminated audio jacks

• N/A

• Voltage detection
• Temperature detection
• Fan speed detection
• Overheating warning
• Fan fail warning
• Fan speed control


• 256 Mb Flash ROM, UEFI AMI BIOS


• ASUS Q-Design
  ASUS Q-DIMM
  ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [green])
  ASUS Q-Slot
• ASUS Thermal Solution
  Aluminum M.2 heatsink
• ASUS EZ DIY
  BIOS FlashBack button
  BIOS FlashBack LED
  Procool II
  Pre- mounted I/O shield
  SafeSlot
• AURA Sync
  Standard RGB header
  Addressable Gen 2 RGB header

• Driver and software disc

• Support for Windows 10 64-bit

• Mini-ITX Form Factor, 17.0cm x 17.0cm
