CPU
  • Intel Socket LGA1200: Support 10th & 10th Gen Intel Core i3 / i5 / i7 / i9 / Celeron
Chipset
  • Intel H510 Chipset
Memory
  • 2 x DIMM, DDR4 2800 / 2666 / 2400 / 2133 Non-ECC, Un-buffered Memory
  • Dual Channel Memory Architecture
Onboard Graphics

Integrated Graphics Processor:

  • 1 x DisplayPort Port
  • 1 x HDMI Port
Audio

Onboard Audio

  • 6-Channel High Definition Audio
LAN

1 x Realtek LAN Controller

  • 10 / 100 / 1000 Mbps
Wireless Communication ModuleNone
Expansion Slots

PCI-Express x16

  • 1 x PCIe 4.0 x16

PCI-Express x1

  • 1 x PCIe 3.0 x1
Storage Interface

M.2

  • 1 x M.2 2280 PCIe Gen 3

SATA:

  • 3 x SATA 3.0 6Gb/s Ports
USB

Rear USB (Total 2 ports)

  • 2 x USB 3.0 Type-A
  • 2 x USB 2.0

Front USB (Total 6 ports)

  • 2 x USB 2.0 headers support 4 additional USB 2.0 ports
  • 1 x USB 3.0 header supports 2 additional USB 3.0 Type-A ports

Internal I/O Connectors

USB:

  • 2 x USB 2.0 support an additional 4 USB 2.0 ports
  • 1 x USB 3.0 support an additional 2 USB 3.0 ports

Audio:

  • 1 x Front panel audio header
Back Panel Connectors
  • 1 x PS/2 Mouse
  • 1 x PS/2 Keyboard
  • 1 x DisplayPort Port
  • 1 x HDMI Port
  • 2 x USB 3.0 Type-A Ports
  • 2 x USB 2.0 Ports
  • 1 x LAN Port
  • 3 x Audio Jacks
I/O Controller
  • Not Specified
H/W Monitoring
  • Temperature detection
  • Fan speed detection
BIOS
  • Not Specified
Unique Features

N/A

Bundled Software

None

Operating System
  • Support for Windows
Form Factor
  • Micro ATX Form Factor, 22.0cm x 17.0cm

Manufacturer
Manufacturer's WebsiteLink *
Product WebsiteLink *
Warranty Information
Warranty Duration1 Year
* These links will redirect to an external website which may be governed by its own privacy policy. We do not share customer information with external sites outside of what's lined out in our Privacy Policy.

Write a review

Note: HTML is not translated!
    Bad           Good

Arktek AK-H510M, Intel H510 Chipset, LGA1200, DDR4, Micro ATX Desktop Motherboard

- Socket LGA1200, Intel H510 Chipset
- Supports Core i3 / i5 / i7 / i9 / Celeron
- 2 x DDR4 DIMM Slots, up to DDR4-2800
- 1 x PCIe 4.0 x16 Slot
- 1 x PCIe 3.0 x1 Slot
- 1 x M.2 PCIe 3.0 NVMe Slot
- 3 x SATA Ports
- 1Gbps LAN
- 2 x Rear USB 3.0 Type-A, 2 x Rear USB 2.0 Type-A
- Form Factor: Micro ATX
- 1 Year Warranty

  • Product Code: AK-H510M
