• 11th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors

• 10th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors / Intel Core i3 processors/ Intel Pentium processors / Intel Celeron processors*
  * Limited to processors with 4 MB Intel Smart Cache, Intel Celeron G5xx5 family.
• L3 cache varies with CPU

• Intel H510 Express Chipset


• 11th Generation Intel Core i9 / i7 / i5 processors:
  Support for DDR4 3200 / 3000 / 2933 / 2666 / 2400 / 2133 MHz memory modules
• 10th Generation Intel Core i9 / i7 processors:
  Support for DDR4 2933 / 2666 / 2400 / 2133 MHz memory modules
• 10th Generation Intel Core i5 / i3 / Pentium / Celeron processors:
  Support for DDR4 2666 / 2400 / 2133 MHz memory modules
• 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
• Dual channel memory architecture
• Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
• Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
• Support for Extreme Memory Profile (XMP) memory modules

Integrated Graphics Processor - Intel HD Graphics support

• 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
  * When the D-Sub port and DisplayPort are connected at the same time, images will output from the DisplayPort only.
• 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
  * The DVI-D port does not support D-Sub connection by adapter.
• 1 x HDMI ports, supporting a maximum resolution of 4096x2160@30 Hz
  * Support for HDMI 1.4 version and HDCP 2.3.
• 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
  * Support for DisplayPort 1.2 version and HDCP 2.3
  * When the D-Sub port and DisplayPort are connected at the same time, images will output from the DisplayPort only.
• Support for up to 2 displays at the same time

• Realtek Audio CODEC

• High Definition Audio
• 2/4/5.1/7.1-channel
  * To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.

• Realtek GbE LAN chip (1 Gbit/100 Mbit)

• None

• 1 x PCI Express x16 slot, running at x16
  (The PCI Express x16 slot conforms to PCI Express 4.0 standard.)
  * Supported by 11th Generation processors only.
• 2 x PCI Express x1 slots
  (The PCI Express x1 slots conform to PCI Express 3.0 standard.)

• None


Chipset:

• 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
  * The PCIEX1_1 slot shares bandwidth with the M.2 connector. When the PCIEX1_1 slot is populated, the M.2 connector supports up to PCIe 3.0 x2 SSD only.
• 4 x SATA 6Gb/s connectors
  * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

Chipset:

• 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)

Chipset+USB 2.0 Hub:

• 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB header)

• 1 x 24-pin ATX main power connector

• 1 x 8-pin ATX 12V power connector
• 4 x SATA 6Gb/s connectors
• 1 x CPU fan header
• 2 x system fan headers
• 1 x RGB LED strip header
• 1 x front panel header
• 1 x front panel audio header
• 1 x speaker header
• 1 x USB 3.2 Gen 1 header
• 2 x USB 2.0/1.1 headers
• 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
• 1 x serial port header
• 1 x Clear CMOS jumper

＊All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24W.

• 1 x PS/2 keyboard port

• 1 x PS/2 mouse port
• 1 x D-Sub port
• 1 x DVI-D port
• 1 x DisplayPorts
• 1 x HDMI port
• 2 x USB 3.2 Gen 1 ports
• 4 x USB 2.0/1.1 ports
• 1 x RJ-45 port
• 3 x audio jacks

• iTE I/O Controller Chip

• Voltage detection
• Temperature detection
• Fan speed detection
• Overheating warning
• Fan fail warning

• Fan speed control
  * Whether the fan speed control function is supported will depend on the cooler you install.


• 1 x 256 Mbit flash
• Use of licensed AMI UEFI BIOS
• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

• Support for APP Center
  * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
  @BIOS
  Ambient LED
  EasyTune
  Fast Boot
  Game Boost
  ON/OFF Charge
  Smart Backup
  System Information Viewer
• Support for Q-Flash
• Support for Xpress Install


• Norton Internet Security (OEM version)
• Realtek 8118 Gaming LAN Bandwidth Control Utility

• Support for Windows 10 64-bit

• Micro ATX Form Factor, 24.4cm x 21.0cm
