PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.
| CPU | - Supports 10th Gen Intel Core and Pentium Gold / Celeron processors for LGA 1200 socket
|
| Chipset | - Intel H410 Express Chipset
|
| Memory | - 2x DDR4 memory slots, support up to 64GB
- Intel Core i7/ i9
Supports up to DDR4 2933 MHz - Intel Core i5 and below
Supports up to DDR4 2666 MHz - Supports Dual-Channel mode
- Supports non-ECC, un-buffered memory
- Supports Intel Extreme Memory Profile (XMP)
|
| Onboard Graphics | - 1x DVI-D port, supports a maximum resolution of 1920x1200 @60Hz
- 1x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @30Hz
|
| Audio | - Realtek ALC892/ALC897 Codec
- 7.1-Channel High Definition Audio
|
| LAN | - 1x Intel I219V Gigabit LAN controller
|
| Wireless Communication Module | |
| Expansion Slots | - 1x PCIe 3.0 x16 slot (From CPU)
- 1x PCIe 3.0 x1 slot (From PCH)
- 1x M.2 slot with E key for WiFi module only
|
| Multi-Graphics Technology | |
| Storage Interface | Chipset - 4x SATA 6Gb/s ports
- 1x M.2 slot (Key M)
M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices
|
| USB | Chipset - 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB 3.2 Gen 1 5Gbps connector)
- 6x USB 2.0 ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 2.0 connector)
|
| Internal I/O Connectors | - 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 4 x SATA 6Gb/s connectors
- 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports)
- 1 x USB 3.2 Gen1 5Gbps connector (supports additional 2 USB 3.2 Gen1 5Gbps ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin system fan connector
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x Serial port connector
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Clear CMOS jumper
- 4 x EZ Debug LED
|
| Back Panel Connectors | - 1 x Keyboard / Mouse
- 1 x LAN
- 1 x DVI-D
- 1 x HDMI
- 2 x USB 3.2 Gen 1 5Gbps Type-A
- 4 x USB 2.0
- 3 x Audio Connectors
|
| I/O Controller | |
| H/W Monitoring | - Voltage detection
- Temperature detection
- Fan speed detection
- Overheating warning
- Fan fail warning
- Fan speed control
* Whether the fan speed control function is supported will depend on the fan you install.
|
| BIOS | |
| Unique Features | |
| Bundled Software | |
| Operating System | - Support for Windows 10 64-bit
|
| Form Factor | - Micro-ATX Form Factor, 23.6cm x 19.0cm
|
| Manufacturer |
| Manufacturer's Website | Link * |
| Product Website | Link * |
| Warranty Information |
| Warranty Duration | 3 Years |
