• Supports 10th Gen Intel Core, 11th Gen Intel Core, Pentium Gold and Celeron processors for LGA 1200 socket


• Intel Z490 Express Chipset


• 2 x DDR4 memory slots, support up to 64GB

• Supports 1R 2133/2666/2933 MHz
  1DPC 1R Max speed up to 5000+ MHz
  1DPC 2R Max speed up to 4600+ MHz
• Supports Dual-Channel mode
• Supports non-ECC mode, un-buffered memory
• Supports Intel Extreme Memory Profile (XMP)

• 1x DisplayPort, supports a maximum resolution of 4096x2304 @60Hz

• 1x HDMI port, supports a maximum resolution of 4096x2160 @30Hz
• Intel JHL7540 Thunderbolt 3 Controller
  1x Thunderbolt 3 [Type-C] port on the back panel
  Supports Thunderbolt 3 with a maximum resolution of 3840x2160 @60Hz or DisplayPort 1.4 with a maximum resolution of 4096x2304 @60 Hz
• Maximum shared memory is 1GB

• Realtek ALC1220 Codec
• 7.1-Channel High Definition Audio
• Supports S/PDIF output

• 1x Realtek RTL8125B 2.5G LAN controller


Intel AX201

• The Wireless module is pre-installed in the M.2 [Key-E] slot

• Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz [160MHz] up to 2.4Gbps
• Supports 802.11ac
• WiFi 6
• Supports Bluetooth 5.1, FIPS, FISMA

• 1x PCIe 3.0 x16 slot (From CPU)
  Support up to PCIe 4.0 for 11th Gen Intel CPU
  Support up to PCIe 3.0 for 10th Gen Intel CPU

• N/A

Chipset:

• 4x SATA 6Gb/s ports

• 2x M.2 slots [Key M]
• M2_1 slot
  CPU support mode (From 11th Gen Intel CPU only)- supports PCIe 4.0 x4/3.0 x4
  Chipset support mode-supports PCIe 3.0 x4 and SATA 6Gb/s
  Supports 2280 storage devices
• M2_2 supports up to PCIe 3.0 x4, 2280 storage devices
• Intel Optane Memory Ready
• Supports Intel Smart Response Technology for Intel Core processors
• The SATA2 will be unavailable when installing M.2 SATA device into M2_1 slot.
• Before using Intel Optane memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.

Intel Z490 Chipset

• 2x USB 3.2 Gen2 10Gbps ports [1 Type-A port on the back panel, 1 Type-C internal connector]
• 4x USB 3.2 Gen1 5Gbps ports [2 Type-A ports on the back panel, 2 ports through the internal USB 3.2 Gen1 5Gbps connector]
• 4x USB 2.0 ports [2 Type-A ports on the back panel, 2 ports through the internal USB 2.0 connector]

Intel JHL7540 Thunderbolt 3 Controller

• 1x USB 3.2 Gen2 10Gbps Type-C port on the back panel
• Supports up to 40 Gbps transfer rate with Thunderbolt 3 devices
• Supports up to 10 Gbps transfer rate with USB 3.2 Gen2 10Gbps devices
• Supports up to 5V/3A , 15W power charging
• Supports Daisy-chain up to six Thunderbolt 3 devices

• 1 x 24-pin ATX main power connector

• 1 x 8-pin ATX 12V power connector
• 4 x SATA 6Gb/s connectors
• 2 x M.2 slots [M-Key]
• 1 x USB 3.2 Gen2 10Gbps Type-C port
• 1 x USB 3.2 Gen1 5Gbps connector [supports additional 2 USB 3.2 Gen1 5Gbps ports]
• 1 x USB 2.0 connector [supports additional 2 USB 2.0 ports]
• 1 x 4-pin CPU fan connector
• 1 x 4-pin water-pump fan connector
• 1 x 4-pin system fan connector
• 1 x Front panel audio connector
• 2 x System panel connectors
• 1 x Chassis Intrusion connector
• 2 x 3-pin RAINBOW LED connectors
• 1 x TPM module connector

• 1 x Display port

• 2 x USB 2.0 ports
• 1 x 2.5G LAN
• 2 x Wi-Fi /Bluetooth Antenna Connectors
• 5 x HD Audio Connectors
• 1 x HDMI port
• 2 x USB 3.2 Gen1 5Gbps (Type-A)
• 1 x Thunderbolt 3 (40Gbps)
• 1 x USB 3.2 Gen2 10Gbps (Type-A)
• 1 x Clear CMOS Button
• 1 x Optical S/PDIF Out

• N/A

• Voltage detection
• Temperature detection
• Fan speed detection
• Overheating warning
• Fan fail warning
• Fan speed control
  * Whether the fan speed control function is supported will depend on the fan you install.

• N/A

• N/A

• Driver Disc

• Support for Windows 10 64-bit

• Mini-ITX Form Factor, 17.0cm x 17.0cm
