X870E GAMING PLUS WIFI is designed with durable components to provide great gaming experience. Designed with Wi-Fi 7 and 5G LAN, high-speed USB4, PCIe 5.0 solutions, Supplemental PCIe Power and exclusive EZ DIY features, it's ready for 24/7 non-stop gaming of AMD Ryzen 9000 series processors. MSI motherboards are designed with advanced hardware and technology, well-supporting the demanding computing usage of gaming and AI. Moreover, we also introduce AI to MSI Center and BIOS, making everything more effortless than before.

CPU	AMD Socket AM5 Supports AMD Ryzen 9000 / 8000 / 7000 Series Desktop Processors
Chipset	AMD X870E
Memory	4 x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen 9000 Series Processors max. overclocking frequency: 1DPC 1R Max speed up to 8200+ MT/s 1DPC 2R Max speed up to 6400+ MT/s 2DPC 1R Max speed up to 6400+ MT/s 2DPC 2R Max speed up to 4800+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPO Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only
Onboard Graphics	Integrated Graphics Processor with AMD Radeon Graphics 1 x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz 1 x Type-C DisplayPort USB4 port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K 120Hz
Audio	Realtek ALC897 7.1-Channel High Definition Audio
LAN	Realtek 8126VB 5G LAN 5Gbps / 2.5 Gbps / 1 Gbps / 100 Mbps
Wireless Communication Module	Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4
Expansion Slots	3 x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) Supports PCIe 5.0 x16 (For Ryzen 9000/ 7000 Series processors) Supports PCIe 4.0 x8 (For Ryzen 8700/ 8600/ 8400 Series processors) Supports PCIe 4.0 x4 (For Ryzen 8500/ 8300 Series processor) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) 1 x PCI-E x1 slot PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset)
Storage Interface	3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors) Supports up to PCIe 4.0 x4 (For Ryzen 8000 Series processors) M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280 devices 4x SATA 6G Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1, RAID 5 for M.2 NVMe storage devices RAID 5 configuration is only supported by Ryzen 9000 series processors.
USB	Rear: 4 x USB 2.0 2 x USB 5Gbps Type A 2 x USB 10Gbps Type A 1 x USB 20Gbps Type C 1 x USB 40Gbps Type C Front: 6 x USB 2.0 4 x USB 5Gbps Type A 1 x USB 10Gbps Type C
Internal I/O Connectors	1 x Power Connector(ATX_PWR) 2 x Power Connector(CPU_PWR) 1 x Power Connector(PCIE_PWR 8pin) 1 x CPU Fan 1 x Combo Fan (Pump_Sys Fan) 6 x System Fan 1 x EZ Conn-header (JAF_1) 2 x Front Panel (JFP) 1 x Chassis Intrusion (JCI) 1 x Front Audio (JAUD) 1 x Tuning Controller connector(JDASH) 3 x Addressable V2 RGB LED connector (JARGB_V2) 1 x RGB LED connector(JRGB) 1 x TPM pin header(Support TPM 2.0) 6 x USB 2.0 ports 4 x USB 5Gbps Type A ports 1 x USB 10Gbps Type C ports
Back Panel Connectors	1 x Clear CMOS Button 2 x USB 5Gbps Type-A 2 x USB 10Gbps Type-A 4 x USB 2.0 1 x 5G LAN 2 x Wi-Fi / Bluetooth 1 x Audio connectors 1 x Flash BIOS Button 1 x HDMI 1 x USB 40Gbps Type-C 1 x USB 20Gbps Type-C
I/O Controller	iTE I/O Controller Chip
H/W Monitoring	Voltage detection Temperature detection Fan speed detection Fan fail warning Fan speed control
BIOS	Not Specified
Unique Features	4 x EZ Debug LED 1 x EZ Memory Detection LED
Bundled Software	Drivers
Operating System	Support for Windows 11 64-bit
Form Factor	ATX Form Factor 30.5cm x 24.4cm

Manufacturer
Manufacturer's Website	Link *
Product Website	Link *
Warranty Information
Warranty Duration	3 Years

* These links will redirect to an external website which may be governed by its own privacy policy. We do not share customer information with external sites outside of what's lined out in our Privacy Policy.

Write a review

Your Name

Your Review

Note: HTML is not translated!

Rating Bad Good

MSI X870E GAMING PLUS WIFI, AMD X870E Chipset, Socket AM5, ATX Desktop Motherboard

- Socket AM5, AMD X870E Chipset
- Supports AMD Ryzen 7000, 8000 & 9000 Series Processors
- 4 x DDR5 DIMM Slots, up to 256GB, DDR5-8200+ (OC)
- Supports CUDIMM Memory Modules (Bypass Mode)
- 1 x PCIe 5.0 x16 Slot
- 1 x PCIe 4.0 x16 Slot (x4 Electrical)
- 1 x PCIe 3.0 x16 Slot (x1 Electrical)
- 1 x M.2 PCIe 5.0 NVMe Slot
- 2 x M.2 PCIe 4.0 x4 NVMe Slots
- 4 x SATA Ports, Supports RAID 0 / 1 / 10
- 5Gbps LAN, Wi-Fi 7 & Bluetooth 5.4
- 1 x HDMI 2.1
- 1 x Rear USB Type-C 40Gb/s, 1 x Rear USB Type-C 20Gb/s
- 2 x Rear USB Type-A 10Gb/s, 2 x Rear USB Type-A 5Gb/s
- 4 x Rear USB 2.0/1.1
- 3 x Rear Audio Jacks
- EZ PCIe Clip II Quick-Release Mechanism
- EZ M.2 CLIP II Tool-Less M.2 SSD Installation
- EZ M.2 Shield Frozr II
- EZ Debug LED & EZ Memory Detection LED
- EZ Antenna Quick-Release Wi-Fi Antenna
- Flash BIOS Button - Update BIOS without CPU / RAM / GPU
- 3 x ARGB Gen2 Headers
- Form Factor: ATX
- 3 Year Warranty

Product Code: 7E70-001R
