To meet the Intel ATX 2.52 standard, using Active PFC + Double Forward + DC to DC, combined with a dual-stage EMI circuit. It significantly reduces ripple noise and voltage deviation, providing better electrical performance and compatibility. Supporting 180V-264V wide voltage operation and extreme full-load working conditions under room temperature at a 160V low-voltage grid were supported to avoid voltage instability shutdown. Strictly following global safety standards, beyond competitors, including the 40℃ and 5000m safety levels, meets the requirements for high-temperature and high-altitude areas. A high-quality long-life bearing fan extends operational life by 30% compared to a normal fan and can continuously function for 7×24 hrs in a 40℃ environment. Meanwhile, the aerodynamic design based on PCB layout and flow resistance offers superior stability and quiet operation. Equipped with GAMER STORM's custom-molded sleeved cables significantly enhances the installation and wiring experience.
| Model | R-PF750X-HD0B-JGEU |
| Capacity | 750w |
| 80 PLUS Rating | 80 PLUS Bronze |
| Modular | Non-Modular |
| Lighting | No |
| Fan Size | 120mm |
| ATX 24-pin Connectors | 1 |
| EPS Connectors | 2 x 4+4-pin |
| PCI-Express Connectors | 2 x 6+2-pin |
| SATA Connectors | 6 |
| PATA Connectors | 2 |
| Floppy Connectors | 0 |
| Dimensions | 150mm x 86mm x 140mm |
| Warranty | 3 Years |
| Manufacturer | |
| Manufacturer's Website | Link * |
| Product Website | Link * |
| Warranty Information | |
| Warranty Duration | 3 Years |
DEEPCOOL PF750X 80 PLUS Bronze Non-Modular ATX PSU, 750w
- ATX Desktop PSU
- Power Capacity: 750w
- Efficiency Rating: 80 Plus Bronze
- Cybenetics Bronze Certified
- Non-Modular Design
- 2 x 4+4 Pin EPS Connector
- 2 x PCIe 6+2 Pin Connector
- 6 x SATA Connectors
- 120mm Fan
- Custom-Molded Sleeved Cables
- OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO Protection
- 3 Year Warranty
- Product Code: R-PF750X-HD0B-JGEU
