OVERVIEW
The AeroCool B509A Flow is a mid-tower case that combines powerful performance with sleek, functional design. Its full mesh front panel maximizes airflow while showcasing your build, and with support for GPUs up to 340mm and liquid coolers up to 360mm, it’s ready for high-performance hardware. Equipped with eight fan slots, magnetic dust filters, and a tempered glass side panel, the B509A Flow keeps your system cool, clean, and looking sharp.

Airflow Meets Style
Designed with a sleek, full mesh front panel, the B509A Flow maximizes airflow while maintaining a bold, modern look. Keep your system cool and performing at its best without compromising on aesthetics.

Optimized Cooling Potential
Equipped with eight total fan slots, including space for up to five 140mm fans, the B509A Flow ensures efficient heat dissipation. Keep your components running at peak performance with superior airflow.

Liquid Cooling Excellence
Support for radiators up to 360mm on the front and 120mm on the rear ensures optimal thermal performance.

Room for High-Performance Hardware
With support for GPUs up to 340mm, liquid coolers up to 360mm, and CPU coolers up to 158mm, this case is built for powerful setups. Enjoy smooth gaming and seamless multitasking with the hardware you need.

Easy Maintenance Filters
Keep your system clean and efficient with the magnetic top filter and removable bottom filter, designed for effortless cleaning and effective dust prevention.

Showcase Your Build
A sleek tempered glass side panel lets you display your components with pride. Highlight your RGB lighting and premium hardware with a clear, stylish view.

ModelB509A Flow-G-BK-v1
ColourBlack
LightingFixed-Mode ARGB
MaterialsSPCC, ABS, Tempered Glass
Dimensions451mm x 207mm x 401mm
Form FactorMid Tower
Motherboard SupportATX, Micro ATX, Mini-ITX
Front I/O

1 x USB 3.2 Gen1 Type-A
2 x USB 2.0 Type-A
1 x Headphone Out/Mic In
1 x Power Button
1 x Reset Button

Side PanelTempered Glass
Drive Bays

5.25": 0
3.5" / 2.5" Combo: 1
3.5": 1
2.5": 4

Expansion Slots7
Fan Support

Front: 3 x 120mm / 3 x 140mm (3 x 120mm fixed-mode ARGB fans included)
Top: 2 x 120mm / 2 x 140mm (2 x 120mm fixed-mode ARGB fans included)
Back: 1 x 120mm (1 x 120mm fixed-mode ARGB fan included)
PSU Shroud: 2 x 120mm
Side: None

Radiator Support

Front: 360mm / 280mm / 240mm / 140mm / 120mm
Top: None
Back: 120mm
PSU Shroud: None
Side: None

Clearances

CPU Cooler: 158mm
GPU Length: 340mm
PSU Length: 185mm

WeightNot Specified

Manufacturer
Manufacturer's WebsiteLink *
Product WebsiteLink *
Warranty Information
Warranty Duration2 Years
* These links will redirect to an external website which may be governed by its own privacy policy. We do not share customer information with external sites outside of what's lined out in our Privacy Policy.

Write a review

Note: HTML is not translated!
    Bad           Good

AeroCool B509A FLOW Fixed-Mode ARGB Tempered Glass Mid Tower ATX Case — Black

Black

- High Air Flow Design To Keep Components Cool
- Mid Tower ATX Form Factor
- Colour: Black
- Tempered Glass Side Panel

- 1 x USB Type-A 5Gb/s Port
- 2 x USB 2.0 Ports
- 1 x 3.5mm Combo Audio Jack
- 1 x 2.5" / 3.5" Combo Drive Bay
- 1 x 3.5" Drive Bay

- 4 x 2.5" Drive Bays
- Up to 8 x 120mm / 7 x 140mm Fans
- Includes 5 x 120mm Fixed-Mode ARGB Fans
- Supports up to 1 x 360mm Radiator
- Cooler Clearance: Up to 158mm
- GPU Clearance: Up to 340mm
- Top & Bottom Dust Filters
- 2 Year Warranty
