The MasterBox TD500 Mesh embody “airflow performance” in an art form. Three pre-installed ARGB fans flood the system with airflow and lighting, demonstrating the unique effect of ARGB through the Crystalline Tempered Glass. Each element of design is precision-engineered to maximize performance & quality alongside aesthetics, evolving beyond the current limits of lighting and cooling. With advanced technology sculpted into fine art, the MasterBox TD500 Mesh carve its own path to the bleeding edge. Crafted from Cooler Master’s Fine Mesh technology, Polygonal Mesh features a three-dimensional contour and simultaneously provides unobstructed airflow and dust filtration. A crystalline design spans the edges of the tempered glass side panel, precision-engineered for strength as well as aesthetics, elevating how builds and system lighting interact with the design. The included controller allows users to manage systems lighting independently from the hardware configuration and provides the user with 4 additional fan headers in case of need. Pre-installed CF120 ARGB fans provide ample airflow, ensuring low temperatures, high performance, and eye-catching aesthetics during even the most intense gaming sessions. Support for up to seven 120mm fans and 360mm front and top radiator support ensure that performance is not compromised. For enthusiast-grade cooling, two 360mm radiators are supported on the top and front panel to keep the most extreme systems cool. Support for up to a 410mm graphics card, a 165mm CPU cooler, and up to a 180mm PSU in length provides room for upgrades to stay ahead of the game.

ModelMCB-D500D-KGNB65-S02
ColourBlack
LightingARGB
MaterialsSteel, Mesh, Plastic
Dimensions493mm x 217mm x 469mm
Form FactorMid Tower
Motherboard SupportSSI CEB, E-ATX, ATX, Micro ATX, Mini ITX
Front I/O2 x USB 3.2 Gen 1
1 x Headphone Out
1 x Mic In
1 x Power Button
1 x Reset Button
Side PanelTempered Glass
Drive Bays5.25": 0
3.5" / 2.5" Combo: 2
3.5": 0
2.5": 2
Expansion Slots7
Fan SupportFront: 3 x 120mm / 2 x 140mm (3 x 120mm CF120 ARGB fans installed)
Top: 3 x 120mm / 2 x 140mm
Back: 1 x 120mm
Bottom: None
Side: None
Radiator SupportFront: 360mm / 280mm / 240mm / 140mm / 120mm
Top: 360mm / 240mm / 120mm
Back: 120mm
Bottom: None
Side: None
ClearancesCPU Cooler: 165mm
GPU Length: 410mm
PSU Length: 180mm with HDD cage removed
WeightNot Specified


PSU:

ModelMPE-6501-ACABW-B
Capacity650w
80 PLUS RatingBronze
ModularNon-modular
LightingNo
Fan Size120mm
ATX 24-pin Connectors1
EPS Connectors2 x 8-pin
PCI-Express Connectors4 x 6+2-pin
SATA Connectors6
PATA Connectors3
Floppy Connectors0
Dimensions150mm x 86mm x 140mm
Warranty2 Years

NOTE: No SA power cable included.
Manufacturer
Manufacturer's WebsiteLink *
Product WebsiteLink  / Link *
Warranty Information
Warranty Duration2 Years
* These links will redirect to an external website which may be governed by its own privacy policy. We do not share customer information with external sites outside of what's lined out in our Privacy Policy.

Write a review

Note: HTML is not translated!
    Bad           Good

Cooler Master TD500 MESH ARGB Tempered Glass Mid Tower E-ATX Case with MWE Bronze V2 650w PSU — Black
