To enhance product quality and reliability, we have introduced server-grade thermal conductive gel for cooling critical components such as VRAM and MOSFETs. This highly deformable, non-fluid gel provides optimal contact for uneven surface and effectively resists deformation from transport or long-term use, unlike traditional thermal pads. Extended heatsink allows air to pass through, providing better heat dissipation. Complying with NVIDIA's small form factor specification, our graphics cards pack powerful performance into a small form factor, achieving the perfect balance of size and power. The reinforced metal backplate with a bent edge, securely fastened to the I/O bracket, provides exceptional structural integrity. Our newly designed VGA holder offers dozens of customizable mounting options, ensuring your graphics card is securely supported and prevents sagging. Its sleek design allows for discreet installation, enhancing the overall aesthetics of your system.
| Graphics Processing | GeForce RTX 5070 Ti |
| Core Clock | 2497 MHz (Reference Card: 2452 MHz) |
| CUDA Cores | 8960 |
| Ray Tracing Cores | 70 |
| Tensor Cores | 280 |
| Streaming Multi-Processors | 70 |
| Memory Clock | 28000 MHz |
| Memory Size | 16 GB |
| Memory Type | GDDR7 |
| Memory Bus | 256 bit |
| Memory Bandwidth (GB/sec) | 896 GB/s |
| Card Bus | PCI-E 5.0 x16 |
| Digital max resolution | 7680 x 4320 |
| Multi-view | 4 |
| Card size | 304mm x 126mm x 50mm |
| PCB Form | ATX |
| DirectX | 12 Ultimate |
| OpenGL | 4.6 |
| Recommended PSU | 750w |
| Power Connectors | 1 x 16-pin |
| Output | 3 x DisplayPort 2.1a 1 x HDMI 2.1b |
| Multi-GPU Support | No |
| Accessories | VGA Manual 1x 12V-2x6 to 3x PCIe 8-Pin Adapter Versatile VGA Holder Versatile VGA Holder Manual |
| Manufacturer | |
| Manufacturer's Website | Link * |
| Product Website | Link * |
| Warranty Information | |
| Warranty Duration | 3 Years |
Gigabyte GeForce RTX 5070 Ti WINDFORCE OC SFF 16G Graphics Card, 16GB
- NVIDIA GeForce RTX 5070 Ti Graphics Processor
- Base Clock: 2300 MHz
- Boost Clock: Up to 2497 MHz
- CUDA Cores: 8,960 Cores
- 4th Gen Ray Tracing Cores: 70 Ray Tracing Cores
- 5th Gen Tensor Cores: 280 Tensor Cores
- Memory: 16GB GDDR7
- Effective Memory Clock: 28,000 MHz
- NVIDIA RTX Real Time Ray Tracing
- DLSS 4 AI Rendering Technology
- Reinforced Structure with Metal Backplate
- Included GPU Support
- Server-Grade Thermal Gel
- 3 x DisplayPort 2.1a, 1 x HDMI 2.1b, Maximum 4 Displays
- PCIe 5.0 12VHPWR Power Connector
- 3 Year Warranty
- Product Code: GV-N507TWF3OC-16GD
