• Intel Socket LGA1700 for 12th Gen Intel Core, Pentium Gold and Celeron Processors

• Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0

• Intel Z690 Express Chipset


• 4 x DIMM, Max. 128GB, DDR4 5333(OC) / 5133(OC) / 5000(OC) / 4800(OC) / 4600(OC) / 4400(OC) / 4266(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3333(OC) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 Non-ECC, Un-buffered Memory

• Dual Channel Memory Architecture
• Supports Intel Extreme Memory Profile (XMP)
• OptiMem II

Integrated Graphics Processor-Intel HD Graphics support:

• 1 x DisplayPort
  * Supports 8K@60Hz as specified in DisplayPort 1.4.
• 1 x HDMI port
  * Supports 4K@60Hz as specified in HDMI 2.1.

ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080

• Impedance sense for front and rear headphone outputs
• Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
• High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
• Supports up to 32-Bit/384 kHz playback
• Audio Features
  SupremeFX Shielding Technology
  Savitech SV3H712 AMP
  Premium audio capacitors
  Audio cover
  * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
  * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

• 1 x Intel 2.5Gb Ethernet
• ASUS LANGuard

Intel Wi-Fi 6

• 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
• Supports 2.4/5GHz frequency band
• Bluetooth v5.2

• 1 x PCIe 5.0/4.0/3.0 x16 slot(s)

* Please check PCIe bifurcation table in support site.

Intel Z690 Chipset

• 1 x PCIe 3.0 x16 slot (supports x4 mode)
• 1 x PCIe 3.0 x1 slot
* Support Intel Optane Memory H Series on PCH-attached PCIe slot.

• Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies


Supports 3 x M.2 slots and 4 x SATA 6Gb/s ports

Intel 12th Gen Processors

• M.2_1 slot (Key M), type 2242/2260/2280/22110
  Intel 12th Gen processors support PCIe 4.0 x4 mode.

Intel Z690 Chipset

• M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

• M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
• M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
• 6 x SATA 6Gb/s ports
  * Intel Rapid Storage Technology supports NVMe RAID 0/1/5, SATA RAID 0/1/5/10
  * When M.2_4 is operating in SATA mode, SATA6G_2 will be disabled
  * RAID configuration and optical disc drives are not supported on the SATA6G_E1-2 ports

Rear USB: Total 10 ports

• 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)

• 3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C)
• 4 x USB 3.2 Gen 1 ports (4 x Type-A)
• 2 x USB 2.0 ports (2 x Type-A)

Front USB: Total 7 ports

• 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C)

• 1 x USB 3.2 Gen 1 header support(s) additional 2 USB 3.2 Gen 1 ports
• 2 x USB 2.0 headers support additional 4 USB 2.0 ports

Fan and Cooling related

• 1 x 4-pin CPU Fan header
• 1 x 4-pin CPU OPT Fan header
• 1 x 4-pin AIO Pump header
• 5 x 4-pin Chassis Fan headers

Power related

• 1 x 24-pin Main Power connector
• 2 x 8-pin +12V Power connectors

Storage related

• 4 x M.2 slots (Key M)
• 6 x SATA 6Gb/s ports

USB

• 1 x USB 3.2 Gen 2x2 connector (support USB Type-C)

• 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
• 2 x USB 2.0 headers support additional 4 USB 2.0 ports

Miscellaneous

• 3 x Addressable Gen 2 headers

• 1 x AURA RGB header
• 1 x Clear CMOS header
• 1 x CPU Over Voltage jumper
• 1 x 12-1 pin Front Panel Audio header (AAFP)
• 1 x S/PDIF Out header
• 1 x SPI TPM header (14-1pin)
• 1 x 20-3 pin System Panel header with Chassis intrude function
• 1 x Thermal Sensor header
• 1 x Thunderbolt header

• 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)

• 3 x USB 3.2 Gen 2 ports (2 x Type-A, 1 x USB Type-C)
• 4 x USB 3.2 Gen 1 ports (4 x Type-A)
• 2 x USB 2.0 ports (2 x Type-A)
• 1 x DisplayPort
• 1 x HDMI port
• 1 x Wi-Fi Module
• 1 x Intel 2.5Gb Ethernet port
• 5 x Audio jacks
• 1 x BIOS FlashBack button
• 1 x Clear CMOS button

• Not Specified

• Voltage detection
• Temperature detection
• Fan speed detection
• Water cooling flow rate detection
• Fan fail warning

• Fan speed control
  * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

• 256 Mb Flash ROM, UEFI AMI BIOS


Extreme Engine Digi+

• 5K Black Metallic Capacitors

ASUS Q-Design

• M.2 Q-Latch
• PCIe Slot Q-Release
• Q-DIMM
• Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
• Q-Slot

ASUS Thermal Solution

• M.2 heatsink backplate
• M.2 heatsink
• VRM heatsink design

ASUS EZ DIY

• BIOS FlashBack button
• BIOS FlashBack LED
• Clear CMOS button
• CPU Socket lever protector
• ProCool II
• Pre-mounted I/O shield
• SafeSlot
• SafeDIMM

AURA Sync

• AURA RGB header
• Addressable Gen 2 headers

ASUS HYDRANODE

• 1 x 12-1 pin Front Panel Audio header (AAFP)
• 1 x Chassis fan support (CHA_FAN1P)

ROG Exclusive Software

• GameFirst VI
• ROG CPU-Z
• Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion
• Sonic Radar III
• DTS Sound Unbound
• Anti-virus software

ASUS Exclusive Software

• Armoury Crate
  AIDA64 Extreme (60 days free trial)
  AURA Creator
  AURA Sync
  Fan Xpert 4
  Two-Way AI Noise Cancelation
• AI Suite 3
  Easy Optimization with AI Overclocking
  TPU
  EPU
  DIGI+ VRM
  Turbo app
• MyAsus
• WinRAR

UEFI BIOS

• AI Overclocking Guide
• ASUS EZ DIY
  ASUS CrashFree BIOS 3
  ASUS EZ Flash 3
  ASUS UEFI BIOS EZ Mode

FlexKey

MemTest86

• Support for Windows 10/11 64-bit

• ATX Form Factor, 30.5cm x 24.4cm
