• Support for Intel Xeon W-3175X Scalable processor in the LGA3647 Socket P (Narrow)

• L3 cache varies with CPU

• Intel C621 Chipset


• 12 x DDR4 DIMM sockets supporting up to 192 GB of system memory

• 6 channel memory architecture
• Support for DDR4 4200(O.C.) / 4000(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz
• Support for ECC Registered DIMM memory modules
• Support for ECC Un-buffered DIMM memory modules
• Support for Extreme Memory Profile (XMP) memory modules

• None

• Realtek ALC1220-VB codec
  * The back panel line out jack supports DSD audio.
• High Definition Audio
• 2/4/5.1/7.1-channel

• Support for S/PDIF Out


• 2 x Intel GbE LAN chips (10/100/1000 Mbit)

• None

• 2 x PCI Express x16 slots, running at x16 (PCIEX16_1/2)
  * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16_1 slot.
• 4 x PCI Express x16 slots, running at x8 (PCIEX8_1/2/3/4)
  * The PCIEX8_1 slot shares bandwidth with the PCIEX16_1 slot and the PCIEX8_3 with PCIEX16_2. When PCIEX8_1/PCIEX8_3 is populated, PCIEX16_1/PCIEX16_2 operates at up to x8 mode.
• 1 x PCI Express x16 slot, running at x4 (PCIEX4)
  (All of the PCI Express slots conform to PCI Express 3.0 standard.)

• Support for NVIDIA Quad-GPU SLI and 4-Way/3-Way/2-Way NVIDIA SLI technologies

• Support for AMD Quad-GPU CrossFire and 4-Way/3-Way/2-Way AMD CrossFire technologies

Chipset:

• 8 x SATA 6Gb/s connectors

• Support for RAID 0, RAID 1, RAID 5, and RAID 10
• 1 x U.2 connector

Chipset:

• 5 x USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header, 1 onboard)

• 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

• 2 x 24-pin ATX main power connectors

• 4 x 8-pin ATX 12V power connectors
• 2 x OC_PEG power connectors
• 1 x CPU fan header
• 1 x water cooling CPU fan header
• 4 x system fan headers
• 2 x system fan/water cooling pump headers
• 2 x addressable LED strip headers
• 2 x addressable LED strip power select jumpers
• 2 x RGB LED strip headers
• 8 x SATA 6Gb/s connectors
• 1 x U.2 connector
• 2 x SATA power headers
• 2 x SATA detection headers
• 1 x power information detection header
• 1 x front panel header
• 1 x front panel audio header
• 1 x S/PDIF Out header
• 1 x USB 3.1 Gen 1 header
• 1 x USB 3.1 Gen 1 port
• 1 x USB 2.0/1.1 header
• 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
• 1 x Intel® VROC Upgrade Key header
• 1 x serial port header
• 1 x Clear CMOS jumper
• 1 x reset button
• 1 x power button
• 2 x temperature sensor headers
• 1 x BIOS switch
• 1 x buzzer

• 1 x PS/2 keyboard/mouse port

• 4 x USB 2.0/1.1 ports
• 2 x USB 3.1 Gen 1 ports
• 2 x RJ-45 ports
• 1 x optical S/PDIF Out connector
• 5 x audio jacks

• iTE I/O Controller Chip

• Voltage detection
• Temperature detection
• Fan speed detection
• Water cooling flow rate detection
• Overheating warning
• Fan fail warning
• Fan speed control
  * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.


• 2 x 256 Mbit flash
• Use of licensed AMI UEFI BIOS
• Support for DualBIOS
• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

• Support for @BIOS

• Support for Q-Flash
• Support for RGB Fusion
• Support for System Information Viewer

• Norton Internet Security (OEM version)

• Support for Windows 10 64-bit

• E-ATX Form Factor; 38.6cm x 35.9cm

• (Please refer to "Chassis support list" for more information.)
• Chassis support list:
• Chassis that supports HPTX
• CORSAIR Obsidian Series™ 900D (Validated)
• PHANTEKS Enthoo Elite
