• 1st and 2nd Generation Intel Xeon Scalable Processors, Dual LGA 3647 Socket P (Square) with 2 UPI support of up to 10.4 GT/s, CPU TDP support up to 165W


• Intel C621 Chipset


• 8 x DDR4 DIMM sockets supporting up to 1 TB of system memory

• 8 channel memory architecture (4 channel per CPU)
• Support for DDR4 2666 MHz memory modules if use a Skylake CPU
• Support for DDR4 2933 MHz memory modules if use a Cascade lake CPU
• Support for ECC RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS memory modules

ASPEED AST2500:

• 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz

• None

• 1 x Realtek RTL8211E chip (10/100/1000 Mbit) (LAN1)

• 2 x Intel 210AT GbE LAN chips (10/100/1000 Mbit) (LAN2, LAN3)

• None

• 2 x PCI Express x16 slots, running at x16 (PCIEX16_3, PCIEX16_5)

• 1 x PCI Express x16 slot, running at x8 (PCIEX8_1)
• 2 x PCI Express x8 slots, running at x8 (PCIEX8_2, PCIEX8_6)
• 1 x PCI Express x8 slot, running at x4 (PCIEX4_4)
  (All of the PCI Express x16 slots conform to PCI Express 3.0 standard.)

• None

Chipset:

• 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe x4/x2 SSD support)

• 8 x SATA 6Gb/s connectors (I-SATA0~I-SATA7)
• 2 x SATA 6Gb/s connectors (S-SATA0, S-SATA1)
• Support for RAID 0, RAID 1, RAID 5, and RAID 10

Chipset:

• 5 x USB 3.1 Gen 1 ports (2 ports on the back panel, 1 port onboard, 2 ports available through the internal USB header)

• 2 x USB 2.0/1.1 ports available through the internal USB header

• 1 x 24-pin ATX main power connector

• 2 x 8-pin ATX 12V power connectors
• 2 x CPU fan headers
• 6 x system fan headers
• 1 x M.2 Socket 3 connector
• 10 x SATA 6Gb/s connectors
• 2 x SATA DOM power headers
• 1 x PMBus connector
• 1 x Intel VROC Upgrade Key header
• 1 x front panel header
• 1 x USB 3.1 Gen 1 header
• 1 x USB 3.1 Gen 1 port
• 1 x USB 2.0/1.1 header
• 1 x Trusted Platform Module(TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
• 1 x serial port connector
• 1 x chassis intrusion header
• 3 x SATA SGPIO headers
• 1 x SMD_VMD header
• 1 x IPMB connector
• 1 x SMB connector
• 1 x wake on LAN header
• 1 x Clear CMOS jumper
• 1 x VGA jumper
• 1 x Watch-Dog timer jumper
• 1 x VRM SMB Clock jumper
• 1 x VRM SMB Data jumper
• 1 x UID button
• 1 x buzzer

• 1 x D-Sub port

• 3 x RJ-45 ports
• 2 x USB 3.1 Gen 1 ports

• ASPEED AST2500 BMC chip

• Voltage detection
• Temperature detection
• Fan speed detection
• Fan speed control
  * Whether the fan speed control function is supported will depend on the fan you install.

• 1 x 256 Mbit flash
• Use of licensed AMI UEFI BIOS
• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

• N/A

• None

• Windows server 2012/2016/2019

• Linux
• VMware EXSi 6.5/6.7

• CEB Form Factor; 30.5cm x 26.7cm
