• LGA1200 package:

• Intel Xeon W series processors
  10th Generation Intel Core processors/Intel Pentium processors/ Intel Celeron processors
• L3 cache varies with CPU

• Intel W480 Express Chipset


• Intel Xeon W-1290/W-1270 series processors/Intel Core i9/i7 processors:
  Support for DDR4 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz memory modules
• Intel Xeon W-1250 series processors/Intel Core i5/i3/Pentium/Celeron processors:
  Support for DDR4 2666/2400/2133 MHz
• 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
• Dual channel memory architecture
• Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
  * To support ECC, you must install an Intel Xeon processor.
• Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
• Support for Extreme Memory Profile (XMP) memory modules

Integrated Graphics Processor-Intel HD Graphics support:

• 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
  * Support for HDMI 1.4 version and HDCP 2.3.
• 2 x DisplayPorts, supporting a maximum resolution of 4096x2304@60 Hz
  * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.

Support for up to 3 displays at the same time

Maximum shared memory of 512 MB

• Realtek ALC1220-VB codec
  * The back panel line out jack supports DSD audio
• High Definition Audio
• 2/4/5.1/7.1-channel

• Support for S/PDIF Out


• 1 x Intel 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit) (LAN2)
• 1 x Intel Gbe LAN chip (1 Gbit/100 Mbit) (LAN1)

• None

• 1 x PCI Express x16 slot, running at x16 (PCIEX16)
  * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
• 1 x PCI Express x16 slot, running at x8 (PCIEX8)
  * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
• 2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
  * The PCIEX4_2 slot shares bandwidth with the M2M_SB connector. The PCIEX4_2 slot becomes unavailable when a device is installed in the M2M_SB connector.
• 1 x PCI Express x1 slot
  (All of the PCI Express slots conform to PCI Express 3.0 standard.)
• 1 x M.2 Socket 1 connector for an Intel® CNVi wireless module only (CNVI)

Supports up to ASPM L1.2 power management protocols.

• Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies


Chipset:

• 1 x M.2 connector (Socket 3, M key, type 2280/22110 PCIe x4/x2 SSD support) (M2A_CPU)

• 1 x M.2 connector (Socket 3, M key, type 2280/22110 SATA and PCIe x4/x2 SSD support) (M2M_SB)
• 8 x SATA 6Gb/s connectors (SATA3 0~7)
• Support for RAID 0, RAID 1, RAID 5, and RAID 10
  * Refer to "1-8 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
• Intel Optane Memory Ready

ASMedia ASM1061 chip:

• 2 x SATA 6Gb/s connectors (GSATA3 0~1), supporting AHCI mode only

M.2 connectors support up to ASPM L1.2 PCIe power management protocols.

Chipset:

• 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header
• 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
• 3 x USB 3.2 Gen 1 ports on the back panel
• 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

Chipset+1 USB 3.2 Hub:

• 3 x USB 3.2 Gen 1 ports (1 port onboard, 2 ports available through the internal USB header)

• 1 x 24-pin ATX main power connector

• 1 x 8-pin ATX 12V power connector
• 1 x 4-pin ATX 12V power connector
• 1 x PMBUS (Power Information Detection) header
• 2 x M.2 Socket 3 connectors
• 10 x SATA 6Gb/s connectors
• 2 x SATA DOM power connectors
• 2 x SATA detection headers
• 1 x CPU fan header
• 1 x water cooling CPU fan header
• 2 x system fan headers
• 2 x system fan/water cooling pump headers
• 1 x front panel header
• 1 x front panel audio header
• 1 x USB 3.2 Gen 1 port (USB30_OB)
• 1 x USB Type-C header, with USB 3.2 Gen 2 support
• 1 x USB 3.2 Gen 1 header
• 1 x USB 2.0/1.1 header
• 2 x Thunderbolt add-in card connectors
• 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
• 2 x serial port headers
• 2 x temperature sensor headers
• 1 x power button
• 1 x reset button
• 1 x Clear CMOS button
• 1 x Clear CMOS jumper
• 1 x Q-Flash Plus button

• 1 x PS/2 keyboard/mouse port

• 1 x HDMI port
• 2 x DisplayPorts
• 1 x USB 3.2 Gen 2 Type-A port (red)
• 3 x USB 3.2 Gen 1 ports
• 4 x USB 2.0/1.1 ports
• 2 x RJ-45 ports
• 1 x optical S/PDIF Out connector
• 5 x audio jacks

• iTE I/O Controller Chip

• Voltage detection
• Temperature detection
• Fan speed detection
• Overheating warning
• Fan fail warning
• Fan speed control
  * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.


• 1 x 256 Mbit flash
• Use of licensed AMI UEFI BIOS
• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

• Support for APP Center
  * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
  @BIOS
  System Information Viewer
• Support for Q-Flash Plus
• Support for Q-Flash
• Support for Xpress Install


• Norton Internet Security (OEM version)
• cFosSpeed

• Support for Windows 10 64-bit

• ATX Form Factor, 30.5cm x 24.4cm
