Customizable status LED bar with RGB lights. Built-in WiFi for mobile monitoring (Android/iOS Apps are available). Supports USB On-the-Go function. Reserved communication port for BMS (RS485, CAN-BUS or RS232). Replaceable fan design for ease of maintenance. Battery independent function. Enhanced AC/Solar charger to 120A. Built-in anti-dust kit. Parallel operation up to 6 units.
| Model | RCT-AXMAX-8K48V |
| Rated Power | 8000 VA / 8000 W |
| Input | Voltage: 230 VAC Selectable Voltage Range (PCs): 170 - 280 VAC Selectable Voltage Range (Home Appliances): 90 - 280 VAC Frequency Range: 50 Hz / 60 Hz (auto sensing) |
| Output | AC Voltage Regulation (Battery Mode): 230 VAC ± 5% Surge Power: 16000 VA Efficiency (Peak): 90 - 93 % Transfer Time: 10 - 20 ms Waveform: Pure sine wave |
| Battery | Voltage: 48 VDC Floating Charge Voltage: 54 VDC Overcharge Protection: 66 VDC |
| Solar / AC Charger | Solar Charger Type: MPPT Max PV Array Open Circuit Voltage: 500 VDC Max PV Array Power: 8000 W (4000 W x 2) MPPT Range @ Operating Voltage: 90 - 450 VDC Max Solar Charge Current: 120 A Max AC Charge Current: 120 A Max Charge Current: 120 A |
| Dimensions | 147mm x 433mm x 554mm |
| Weight | 18.4 kg |
| Warranty | 1 Year |
RCT Axpert MAX 8000 VA / 8000 W Solar Inverter Charger, 48V
- Product Code: RCT-AXMAX-8K48V
- Availability:
In Stock
Lead Times:
- In Stock with Progenix: Ready for collection/dispatch once payment clears
- In Stock: 1-2 working days until dispatched or ready for collection
- Out Of Stock: Contact us to see if this item will be restocked.
-
R12,131
