• Intel Socket 1151 9th / 8th Gen Intel Core, Pentium Gold and Celeron Processors

• Supports Intel 14 nm CPU
• Supports Intel Turbo Boost Technology 2.0
  * The Intel Turbo Boost Technology 2.0 support depends on the CPU types.

• Intel Z390 Express Chipset


• 4 x DIMM, Max. 128GB, DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz Non-ECC, Un-buffered Memory

• Dual Channel Memory Architecture
• Supports Intel Extreme Memory Profile (XMP)

Integrated Graphics Processor - Intel HD Graphics support

• Multi-VGA output support : HDMI/DisplayPort ports
  * Supports HDMI with max. resolution 4096 x 2160 @ 30 Hz
  * Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz *1

Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider

• ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
  Dual OP Amplifiers
  Impedance sense for front and rear headphone outputs
  Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
  SupremeFX Shielding Technology
  Supports up to 32-Bit/192kHz playback *2
• Audio Feature:
  SupremeFX Shielding Technology
  Optical S/PDIF out port(s) at back panel
  Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
  Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
  Sonic Radar III
  Sonic Studio III + Sonic Studio Link

• Intel I219V

• Anti-surge LANGuard
• ROG GameFirst Technology

• Intel Wireless-AC 9560

• Wi-Fi 802.11 a/b/g/n/ac
• Supports dual band frequency 2.4/5 GHz
• Supports MU-MIMO

• 2 x PCIe 3.0/2.0 x16 (x16 or dual x8)

• 1 x PCIe 3.0/2.0 x16 (max at x4 mode)
• 3 x PCIe 3.0/2.0 x1

• Supports NVIDIA 2-Way SLI Technology

• Supports AMD 3-Way CrossFireX Technology

Chipset:

• 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)*2
• 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
• 6 x SATA 6Gb/s port(s)
• Support Raid 0, 1, 5, 10
• Intel Optane Memory Ready

Chipset:

• 1 x USB 3.1 Gen 2 front panel connector port(s)
• 4 x USB 3.1 Gen 2 port(s) (3 x Type-A+1 x USB Type-C)
• 4 x USB 3.1 Gen 1 port(s) (2 at back panel, blue, 2 at mid-board)
• 6 x USB 2.0 port(s) (2 at back panel, black, 4 at mid-board)

• 1 x Aura Addressable Strip Header(s)

• 1 x AAFP connector
• 2 x Aura RGB Strip Header(s)
• 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
• 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
• 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
• 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
• 6 x SATA 6Gb/s connector(s)
• 1 x M.2_FAN connector
• 1 x CPU Fan connector(s)
• 1 x CPU OPT Fan connector(s)
• 2 x Chassis Fan connector(s)
• 1 x W_PUMP+ connector
• 1 x 24-pin EATX Power connector(s)
• 1 x 8-pin ATX 12V Power connector(s)
• 1 x System panel(s) (Chassis intrusion header is inbuilt)
• 1 x 5-pin EXT_FAN(Extension Fan) connector
• 1 x MemOK! II switch(es)
• 1 x Thermal sensor connector(s)
• 1 x CPU OV
• 1 x Clear CMOS jumper(s)
• 1 x Node Connector(s)
• 1 x 14-1 pin TPM connector
• 1 x COM port header
• 1 x AIO PUMP Header
• 1 x USB 3.1 Gen 2 front panel connector

• 1 x DisplayPort

• 1 x HDMI
• 1 x LAN (RJ45) port(s)
• 4 x USB 3.1 Gen 2 (3 x Type-A+1 x USB Type-C)
• 2 x USB 3.1 Gen 1
• 2 x USB 2.0
• 1 x Optical S/PDIF out
• 5 x Audio jack(s)
• 1 x ASUS Wi-Fi Module

• N/A

• Voltage detection
• Temperature detection
• Fan speed detection
• Overheating warning
• Fan fail warning
• Fan speed control


• 1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, SM BIOS 3.1, ACPI 6.1


• OC Design - ASUS PRO Clock Technology
  Full BCLK range for extreme overclocking performance
• 5-Way Optimization by Dual Intelligent Processors 5
  5-Way Optimization tuning key perfectly consolidates TPU Insight, EPU Guidance, DIGI+ VRM, Fan Expert 4, and Turbo App
• AI Overclocking
• ASUS Optimem II：
  Improved DDR4 Stability
• AURA:
  Aura Lighting Control
  Aura RGB Strip Headers
  Aura Lighting Effects Synchronization with compatible ASUS ROG devices
  Aura Addressable Strip Header(s)
• ASUS Exclusive Features:
  MemOK! II
  AI Suite 3
  Ai Charger
  Armoury Crate
  Pre-mounted I/O Shield
  ASUS NODE: hardware control interface
• ASUS EZ DIY:
  ASUS CrashFree BIOS 3
  ASUS EZ Flash 3
• ASUS Q-Design :
  ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
  ASUS Q-Slot
  ASUS Q-DIMM
• Gaming Aesthetics:
  3D printing friendly
  AURA-RGB Lighting
• Digi+VRM
• M.2 Onboard (The latest transfer technologies with up to 32Gb/s data transfer speeds)
• DIY Friendly Design
  Procool
  SafeSlot
  Digi+ VRM
  DRAM Overcurrent Protection
  Highly Durable components
  ESD Guards
• ROG Exclusive Software
  RAMCache III
  CPU-Z
  GameFirst V
  Sonic Studio III + Sonic Studio Link
  Sonic Radar III

• Driver disc

• Support for Windows 10 64-bit

• ATX Form Factor, 30.5cm x 24.4cm
