• Intel Socket LGA1700 for 12th Gen Intel Core, Pentium Gold and Celeron Processors

• Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0

• Intel B660 Express Chipset


• 4 x DIMM, Max. 128GB, DDR4 5333(OC) / 5000(OC) / 4800(OC) / 4600(OC) / 4400(OC) / 4266(OC) / 4000(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3333(OC) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 Non-ECC, Un-buffered Memory


Integrated Graphics Processor-Intel HD Graphics support:

• 1 x DisplayPort
  * Supports 4K@60Hz as specified in DisplayPort 1.4.
• 2 x HDMI ports
  * Supports 4K@60Hz as specified in HDMI 2.1.

Realtek 7.1 Surround Sound High Definition Audio CODEC

• Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
• Supports up to 24-Bit/192 kHz playback
  * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
• Audio Features
  Audio Shielding
  Premium audio capacitors
  Dedicated audio PCB layers

• 1 x Intel 1Gb Ethernet

• None

• 1 x PCIe 4.0/3.0 x16 slot


• 1 x PCIe 3.0 x16 slot (supports x4 mode)

• 1 x PCIe 3.0 x16 slot (supports x1 mode)
  * Supports Intel Optane Memory H Series on PCH-attached PCIe slot

• N/A


Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports

Intel 12th Gen Processors

• M.2_1 slot (Key M), type 2242/2260/2280

• Intel 12th Gen processors support PCIe 4.0 x4 mode.

Intel B660 Chipset

• M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

• 4 x SATA 6Gb/s ports
  * Intel Rapid Storage Technology supports SATA RAID 0/1/5/10.

Rear USB: Total 6 ports

• 2 x USB 3.2 Gen 2 ports (2 x Type-A )

• 4 x USB 2.0 ports (4 x Type-A)

Front USB: Total 10 ports

• 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports

• 1 x USB 3.2 Gen 1 connector (supports USB Type-C)
• 2 x USB 2.0 headers support additional 4 USB 2.0 ports
• 1 x USB 2.0 header support 1 USB 2.0 port

Fan and Cooling related

• 1 x 4-pin CPU Fan header
• 1 x 4-pin CPU OPT Fan header
• 2 x 4-pin Chassis Fan headers

Power related

• 1 x 24-pin Main Power connector
• 1 x 8-pin +12V Power connector

Storage related

• 2 x M.2 slots (Key M)
• 4 x SATA 6Gb/s ports

USB

• 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports
• 1 x USB 3.2 Gen 1 connector (supports USB Type-C)
• 2 x USB 2.0 headers support additional 4 USB 2.0 ports
• 1 x USB 2.0 header supports 1 USB 2.0 port

Miscellaneous

• 3 x AURA Addressable Gen 2 headers
• 1 x AURA RGB header
• 1 x Clear CMOS header
• 1 x COM Port header
• 1 x Front Panel Audio header (AAFP)
• 1 x LPT header
• 1 x S/PDIF Out header
• 1 x SPI TPM header (14-1pin)
• 1 x 20-3 pin System Panel header with Chassis intrude function

• 2 x USB 3.2 Gen 2 ports (2 x Type-A )

• 4 x USB 2.0 ports (4 x Type-A)
• 1 x DisplayPort
• 2 x HDMI ports
• 1 x Intel 1Gb Ethernet port
• 3 x Audio jacks
• 1 x PS/2 Keyboard/Mouse combo port

• Not Specified

• Voltage detection
• Temperature detection
• Fan speed detection
• Fan fail warning

• Fan speed control
  * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

• 128 Mb Flash ROM, UEFI AMI BIOS


ASUS TUF PROTECTION

• DIGI+ VRM
• Enhanced DRAM Overcurrent Protection
• ESD Guards
• LANGuard
• Overvoltage Protection
• SafeSlot Core+
• Stainless-Steel Back I/O

ASUS Q-Design

• Q-DIMM

• Q-Slot


ASUS Thermal Solution

• M.2 heatsink
• VRM heatsink design

ASUS EZ DIY

• ProCool

AURA Sync

• AURA RGB header
• Addressable Gen 2 headers

ASUS Exclusive Software

• Armoury Crate
  AURA Creator
  AURA Sync
  Fan Xpert 2+
  Two-Way AI Noise Cancelation
• AI Suite 3
  Performance And Power Saving Utility
  TurboV EVO
  EPU
  DIGI+ VRM
• ASUS CPU-Z

Norton Anti-virus software (Free Trial version)

WinRAR

UEFI BIOS

ASUS EZ DIY

• ASUS CrashFree BIOS 3
• ASUS EZ Flash 3
• ASUS UEFI BIOS EZ Mode

• Support for Windows 10/11 64-bit

• Micro ATX Form Factor, 24.4cm x 24.4cm
