ASUS Dual GeForce RTX 5060 Ti combines powerful thermal performance with broad compatibility. Advanced cooling solutions from flagship graphics cards — including two Axial-tech fans for optimizing airflow to the heatsink. Designed in a compact 2.5-slot form factor, delivering more power in less space. These enhancements make ASUS Dual the perfect choice for gamers who want heavyweight graphics performance in a compact build. You can pack high performance into a smaller footprint with this SFF-Ready Enthusiast GeForce card. Look for cases that are compatible with SFF-Ready Enthusiast GeForce Cards to get a sure fit and streamline your PC build. A vented backplate significantly enhance heat dissipation, helping to keep the GPU cooler during intense tasks. This additional airflow helps ensure optimal temperatures, boosting performance, longevity and stability by defending against overheating and thermal throttling. ASUS GPU Guard applies adhesive to secure all four corners to reduce the risk of cracks. The PCB is reinforced by a backplate that adds structural rigidity, helping to prevent flex and to protect components and trace pathways from damage.
| Graphics Processing | GeForce RTX 5060 Ti |
| Core Clock | OC Mode: 2632 MHz (Reference Card: 2572 MHz) Default Mode: 2602 MHz (Reference Card: 2572 MHz) |
| CUDA Cores | 4608 |
| Ray Tracing Cores | 36 |
| Tensor Cores | 144 |
| Streaming Multi-Processors | 36 |
| Memory Clock | 28000 MHz |
| Memory Size | 8 GB |
| Memory Type | GDDR7 |
| Memory Bus | 128 bit |
| Memory Bandwidth (GB/sec) | 448 GB/s |
| Card Bus | PCI-E 5.0 x16 |
| Digital max resolution | 7680 x 4320 |
| Multi-view | 4 |
| Card size | 229 x 120 x 50 mm |
| PCB Form | ATX |
| DirectX | 12 Ultimate |
| OpenGL | 4.6 |
| Recommended PSU | 550w |
| Power Connectors | 1 x 8-pin |
| Output | 3 x DisplayPort 2.1b 1 x HDMI 2.1b |
| Multi-GPU Support | No |
| Accessories | Speedsetup Manual Thank You Card |
| Manufacturer | |
| Manufacturer's Website | Link * |
| Product Website | Link * |
| Warranty Information | |
| Warranty Duration | 3 Years |
ASUS DUAL GeForce RTX 5060 Ti OC Edition 8GB GDDR7 Graphics Card, 8GB
- NVIDIA GeForce RTX 5060 Ti Graphics Processor
- Base Clock: 2407 MHz
- Boost Clock: Up to 2632 MHz
- CUDA Cores: 4,608 Cores
- 4th Gen Ray Tracing Cores: 36 Ray Tracing Cores
- 5th Gen Tensor Cores: 144 Tensor Cores
- Memory: 8GB GDDR7
- Effective Memory Clock: 28,000 MHz
- NVIDIA RTX Real Time Ray Tracing
- DLSS 4 AI Rendering Technology
- Vented Metal Backplate
- Dual BIOS (Performance / Quiet Mode)
- NVIDIA SFF-Ready
- 3 x DisplayPort 2.1b, 2 x HDMI 2.1b, Maximum 4 Displays
- 1 x PCIe 8-Pin Power Connector
- 3 Year Warranty
- Product Code: 90YV0MP2-M0NA00
