The NH-D9L is a premium grade dual tower CPU cooler that has been designed to provide excellent quiet cooling performance at a height of only 110mm. Its comparably low profile (15mm lower than classic 9cm tower coolers such as the NH-U9S) doesn’t only guarantee full 3U compliance but also makes the NH-D9L ideal for compact HTPC and Small Form Factor cases that have airflow paths parallel to the mainboard. Thanks to its 95x95mm footprint, the NH-D9L clears the RAM and PCIe slots on all Intel based and most AMD based ITX mainboards. The included NF-A9 premium fan supports automatic speed control via PWM for outstanding quietness of operation and a second, optional NF-A9 fan can be added for further improved performance in dual fan mode. Topped off with the trusted, pro-grade SecuFirm2 multi-socket mounting system, Noctua’s proven NT-H1 thermal compound and full 6 years manufacturer’s warranty, the NH-D9L forms a highly compact premium package for space-restricted applications.
| Model | NH-D9L |
| Socket Compatibility | Intel: LGA2066, LGA2011-0 & LGA2011-3 (Square ILM), LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 AMD: AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+ (backplate required), AM4 |
| Cooler Height | 110mm |
| Heatsink Material | Aluminium |
| Heatpipes | 4 |
| Fan Size | 1 x 92mm |
| Fan Specs | Speed: 400-2000 RPM |
| Lighting | None |
| Dimensions | 95mm x 95mm x 110mm |
| Weight | 531g |
| Warranty | 6 years |
| Manufacturer | |
| Manufacturer's Website | Link * |
| Product Website | Link * |
| Warranty Information | |
| Warranty Duration | 6 Years |
Noctua NH-D9L CPU Heatsink and Fan, 92mm
END OF LIFE / DISCONTINUED
- Product Code: NH-D9L
- Availability:
Out Of Stock
Lead Times:
- In Stock with Progenix: Ready for collection/dispatch once payment clears. The cut-off for same-day dispatch is 12:00pm on business days.
- In Stock with Supplier: 1-3 business days until dispatched or ready for collection
- Special Order Item: Ordered specially upon request. Contact us for estimated lead times.
- Out Of Stock: Contact us to see if this item will be restocked.
