The Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol, which allows the EAP to boost overall speeds up to 1775 Mbps (1201 Mbps on a 5 GHz band and 574 Mbps on a 2.4 GHz band). With 8 spatial streams, multi-user throughput is incredibly increased to drive more applications. Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability. 100% centralized cloud management of whole network from different sites—all controlled from a single interface anywhere, anytime. 802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted. Band Steering automatically moves dual band devices onto the wider 5GHz band for faster connections. Load Balance ensures large numbers of users have smooth network experiences in high-density business networks. Airtime Fairness increases average network throughput in heavily congested environments. Guest Network provides elevated secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and power up your business.
| Model | TL-EAP620-HD |
| Wireless Standard | Wireless 802.11ax / ac / n / g / b / a |
| Maximum Speed | 5 GHz: Up to 1201 Mbps 2.4 GHz: Up to 574 Mbps |
| Connectivity | 1 x Gigabit RJ45 Ethernet Port (supports IEEE802.3at PoE) |
| WPS | No |
| Security | WEP, WPA Personal / Enterprise, WPA2 Personal / Enterprise, WPA3 Personal / Enterprise Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Rogue AP Detection 802.1X Support |
| Features | 1024-QAM 4× Longer OFDM Symbol OFDMA Multiple SSIDs (Up to 16 SSIDs, 8 for each band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) MU-MIMO Seamless Roaming Band Steering Load Balance Airtime Fairness Beamforming Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/Client |
| Management | Omada Cloud-Based Controller Omada Hardware Controller (OC300) Omada Hardware Controller (OC200) Omada Software Controller Cloud Access: Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) Email Alerts: Yes LED ON/OFF Control: Yes Management MAC Access Control: Yes SNMP: v1, v2c, v3 System Logging Local/Remote Syslog: Local/Remote Syslog SSH: Yes Web-based Management: HTTP/HTTPS L3 Management: Yes Multi-site Management: Yes Management VLAN: Yes |
| Antennas | 4 x Internal |
| Warranty | 2 Years |
| Manufacturer | |
| Manufacturer's Website | Link * |
| Product Website | Link * |
| Warranty Information | |
| Warranty Duration | 2 Years |
TP-Link EAP620 HD AX1800 Dual Band (2.4 / 5GHz) Ceiling Mount Wi-Fi Router / Access Point
- Product Code: TL-EAP620-HD
