The JVAW50 HDMI over Wireless Extender includes a transmitter and receiver kit. It can send a high definition video and audio signal to an HDMI enabled TV set, projector or LCD PC monitor display device with receiver distance up to 60 meters and nearly zero latency. Users can extend other HDMI sources, including DVD players, Blu-ray players, PCs, notebooks and gaming machines (ex. Sony PS4, Nintendo Switch). The JVAW50 is fully HDCP compliant via HDMI, supporting resolutions up to 1080p and stereo digital audio. The extender also supports the transfer of IR remote control signals to the receiver side. Basic product functions and application scenarios: converts the passage of the HDMI or IR signal into a wireless signal, converting it into a flexible means of transmission and reception. It addresses the issue of the TV being too far away from the host by eliminating the need for wires, allowing the TV to be moved outdoors for long distance use. During meetings, projectors or large touch screens mounted high above can also be used to create a wireless conference room and/or a wireless media environment.
SKU | JVAW50 |
HDMI | HDMI Connector: Type-A 19-pin female input x1 HDMI Compliance: HDMI v1.3 HDCP Compliance: HDCP 1.2 |
Video Impedance | 100 Ohms |
HDMI Audio Formats | Stereo digital audio |
Video Resolution | Input: 640x480 to 1600x1200 and 1920x1080, 480p, 576p, 720p, 1080p @ 60/50Hz Output: 640x480, 800x600, 1024x768, 1280x768, 1280x800, 1280x1024, 1360x768, 1366x768, 1400x1050, 1440x900, 1600x900, 1600x1200, 1680x1050, 1920x1080, HDTV 480p, 576p, 720p, 1080p, 480i, 576i, 720i, 1080i |
Wireless | Frequency Range: IEEE 802.11ac (5 GHz Band I, Band IV, CE only Band I) Channel Bandwidth: 20 MHz or 40 MHz or 80 MHz Antennas: Dual external antenna (+5 dBi) Maximum Range: Up to 60 meters Security: 128/256 bit AES based encryption and WPA2 authentication protocol to protect data |
RF Output Power | +15 dBm +/-1 dBm |
IR Return Frequency | 30 - 60 kHz |
Power | Power Jack: DC jack 3.5mm Power Supply Input: 100-240V AC, 50-60 Hz, 0.4A Power Supply Output: 5V DC, 2A, 10W Power Consumption: 5V DC, 6.5W |
Dimensions | 135mm x 76mm x 34mm |
Weight | 150 g |
Contents | 1 x JVAW50 TX 1 x JVAW50 RX 1 x IR blaster cable 1 x IR receiver cable 2 x 5V DC/2A adapter 1 x 1m HDMI cable 1 x 1m USB Micro-B cable 1 x Quick installation guide |
Warranty | 2 Years |
j5 Create JVAW50 Wireless Display HDMI and USB Extender
- Product Code: JVAW50
- Availability: In Stock
-
R2,655
