FRAME 5000D WORKSTATION

MID-TOWER PC CASE

FILL IT UP WITH THE LATEST HARDWARE

The spacious interior is fully compatible with SSI-EEB/CEB motherboards for servers as well as more traditional ATX, E-ATX, and motherboards with reverse connectors.

BUILT FOR DEMANDING WORKLOADS

The interior of the FRAME 5000D WORKSTATION is made for multi-GPU builds with ample vertical clearance for up to four dual-slot GPUs for advanced rendering, CAD, and AI workloads.

BUILT TO ELIMINATE NOISE

The steel side panels feature embedded sound dampening materials for quiet operation, while the massive 200mm intake fans in the ventilated front panel and rear 140mm exhaust fan provide continuous airflow with very little noise.

PLENTIFUL STORAGE

Abundant storage options include dual HDD/SDD combo trays and two dedicated 2.5" SSD trays for a total of 2x 3.5" HDDs and up to 6x 2.5" SSDs for those who need more than just M.2 drives.

WIDE COOLING FLEXIBILITY

Customize your cooling setup with room for up to 9x 120mm fans, plus versatile radiator mounting options including up to dual 360mm radiators in the roof and front.

DIMENSIONS

The FRAME 5000D WORKSTATION has a cavernous interior designed for high-powered builds and abundant cooling.

FAN CAPACITY

Includes 2x 200mm intake fans and 1x 140mm exhaust fan with a total of 9x 120mm or 140mm fan mounts for flexible cooling options on every surface of the interior.

RADIATOR CAPACITY

Mount a 360mm or 280mm radiator in the front and a 360mm or 480mm radiator on top for enhanced airflow.

WORLD-CLASS SUPPORT

Our award-winning service means you can enjoy your gear worry-free.

MODERN FRONT PANEL I/O

Puts your connections within easy reach, including 2x USB 3.2 Gen 1 Type-C ports, 1x USB 3.2 Gen 2x2 Type-C port, and a combination audio/microphone jack.

1. Power Button
2. Headphone / Mic Combo Jack
3. 2x USB 3.2 Gen 1 Type-C Ports
4. USB 3.2 Gen 2x2 Type-C Port

MODULAR AND CUSTOMIZABLE

The FRAME 5000D WORKSTATION is a flexible and powerful platform that can be customized to fit your exact needs. CORSAIR offers UV printing options for personalized branding, as well as bespoke chassis configurations for a wide variety of build diversity thanks to the FRAME Modular Case System.

ModelCC-9011331-WW
ColourWhite
LightingNone
MaterialsSteel, 3D-Y Airflow Steel, Plastic
Dimensions556mm x 250mm x 542mm
Form FactorMid Tower
Motherboard SupportSSI-EEB, SSI-CEB, E-ATX, ATX, Micro ATX, Mini-ITX
Front I/O

2 x USB 3.2 Gen1 Type-C
1 x USB 3.2 Gen2x2 Type-C
1 x Headphone Out/Mic In
1 x Power Button

Side PanelSolid
Drive Bays

5.25": 0
3.5" / 2.5" Combo: 2 / 4
3.5": 0
2.5": 2

Expansion Slots8 (or 3 vertical)
Fan Support

Front: 3 x 120mm / 3 x 140mm / 2 x 200mm (2 x 200mm fans included)
Top: 3 x 120mm / 3 x 140mm
Back: 1 x 120mm / 1 x 140mm (1 x 140mm fan included)
Bottom: 2 x 120mm / 2 x 140mm
Side: None
PSU Shroud: None

Radiator Support

Front: 360mm / 280mm / 240mm / 140mm / 120mm
Top: 420mm / 360mm / 280mm / 240mm / 140mm / 120mm
Back: 140mm / 120mm
Bottom: None
Side: None
PSU Shroud: None

Clearances

CPU Cooler: 175mm
GPU Length: 450mm
PSU Length: 250mm

Weight15.48 kg

Manufacturer
Manufacturer's WebsiteLink *
Product WebsiteLink *
Warranty Information
Warranty Duration2 Years
* These links will redirect to an external website which may be governed by its own privacy policy. We do not share customer information with external sites outside of what's lined out in our Privacy Policy.

Write a review

Note: HTML is not translated!
    Bad           Good

Corsair FRAME 5000D WORKSTATION Modular Tempered Glass Mid Tower SSI-EEB E-ATX Case — White

Black
White

- High Air Flow Design To Keep Components Cool
- Modular FRAME Design with InfiniRail Fan Mounts
- Supports Corsair RapidRoute 2.0 Cable Management
- Mid Tower SSI-EEB E-ATX Form Factor
- Colour: White
- Tempered Glass Side Panel
- Supports Vertically Mounted Graphics Card
- Supports up to 4 x Graphics Cards
- 2 x USB Type-C 5Gb/s Port
- 1 x USB Type-C 20Gb/s Ports
- 1 x 3.5mm Combo Audio Jack
- 2 x 3.5" / 4 x 2.5" Combo Drive Bays
- 2 x 2.5" Drive Bays
- Up to 9 x 120mm / 9 x 140mm / 2 x 200mm Fans
- Includes 2 x 200mm & 1 x 140mm Corsair RS Fans
- Supports up to 1 x 420mm & 1 x 360mm Radiator
- Cooler Clearance: Up to 175mm
- GPU Clearance: Up to 450mm
- Supports Reverse BTF Motherboards
- 2 Year Warranty
